EX-P User Guide
Introduction
Congratulations on purchasing the M-Gear EX-P expression pedal. Please read this User’s Manual to get the most out of the EX-P and enjoy
years of dynamic playing.
Basic Features
The M-Audio EX-P Expression Pedal can be used with any keyboard or controller equipped with an expression, volume or assignable pedal
input. Expression pedals give a player control over various sound parameters, such as volume, filter modulations, and effects, resulting in greater
dynamic range and expression in their performances. By setting the proper control range of the pedal, any player can control their keyboard’s or
controller’s expression parameter to maximize its potential as an effective tool for live sound sculpting.
The M-Audio EX-P is a universal expression pedal, meaning it will work with any device with an expression pedal input. However, there are a
couple of different standards employed between various manufacturers, so M-Audio has included a mode switch on the bottom of the pedal
for compatibility. When in the “M-Audio” position, the EX-P will work with all of M-Audio’s keyboards and controllers. When using the EX-P with
another company’s device, you may need to move this switch to the “Other” position if the pedal is not behaving properly. Keep in mind that the
“M-Audio” position may work on some non-M-Audio products—try both switch settings to find the best match for your equipment.
Contact: If you experience difficulties with your EX-P, please be certain to check the User’s Manual first for additional information. It is
also advisable to check our website at www.m-audio.com, for driver updates and technical support. While there you can also fill out our
technical support form if you have questions or concerns for submission. Alternatively, you can email us at support@m-audio.com,
or contact us by phone at: (626) 633-9055 • Technical support is available by telephone from 7am - 7pm PST
Setup
1. Please insert the EX-P’s 1/4” plug into the expression pedal input of your keyboard or controller.
2. Move the EX-P into the fully forward, or “up,” position. Your instrument will now be set to play at full volume. Adjust the instrument’s output
volume to your desired maximum level.
3. Rock the EX-P pedal back to the “down” position. Your instrument will now be set to play at its minimum volume, which may be silence. If you
do not want to completely turn down your instrument in this position, adjust the EX-P Trim knob until your instrument reaches your desired
“quiet” volume.
4. Moving the pedal back and forth will now change the instrument’s volume between its maximum output and your desired minimum
output.
Technical Info
Modifications not authorized by the manufacturer may void users authority to operate this device.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
VST is a trademark of Steinberg Soft– und Hardware GmbH
ASIO is a trademark of Steinberg Soft– und Hardware GmbH
DirectX is copyright 2002 Microsoft
Sound Studio II, PictureBoard and Music Teacher are copyright 2003 Evolution Electronics Ltd
All rights reserved
Warranty Terms & Registration
Warranty Terms
M-Audio warrants products to be free from defects in materials and workmanship, under normal use and provided that the product is owned
by the original, registered user.
Visit www.m-audio.com/warranty for terms and limitations applying to your specific product.
Warranty Registration
Thank you for registering your new M-Audio product. Doing so immediately both entitles you to full warranty coverage and helps M-Audio
develop and manufacture the finest quality products available. Register online at www.m-audio.com/register to receive FREE product updates
and for the chance to win FREE M-Audio gear.
