M-Audio Keystation 49

NO. Part number Description Spec. Qty. comment
A
keys keys
1
A1
22419 white keys white keys 1
A2
22420 black keys black keys 1
B
37969 MK33 keybed base MK33 keybed base
1
B1
21278B keybed base keybed base(DZ065-V2.0) 1
B2
16382 MT25 lock iron YF8.048.069 1
B3
24121 rubber pad strip 340*14*1.6MM 2
B4
24122 keybed felt (680+0.5)*14*3.5mm 1
B5
25618 KS88ES rubber pad D9.8*H3.8 1
B6
25638 MT61 rubber pad D9*H3 2
B7
25645 KEYRIG49 rubber pad a8.5*b4.5*h3mm 2
B8
A31499 MK33 Main board MK33 Main board Kit 1
B9
L930 MK33 note board MK33 note board Kit 1
B9
L930 MK33 note board MK33 note board Kit 1
B9-1
B32368 MK33Main board MK33 Main board 1
B9-2
24043
keyboard rubber contact A(12 points) keyboard rubber contact A(12 points)
3
B9-3
24044
keyboard rubber contact B(13 points) keyboard rubber contact B(13 points)
1
B9-4
24123 KEYRIG49 keybed felt (675+0.5)*6*3.5mm 1
B9-5
A15551 black film 10000*7*1mm 0.068
C
53960 MK33 top cabinet MK33 top cabinet 1
C1
21551C top cabinet (painted:Pantone 8603C) YF8.080.106(2)(MB1027-V1.0) 1
C2
A23827 button A(Pantone Coolgray 11C) YF8.337.211 1
C3
A23869 button A B(pantone Coolgray 11C) button A B 2
C4
A23870 button C(pantone Coolgray 11C) button C 1
C5
A23871 button B(Pantone Coolgray 11C) YF8.337.212(2) 1
C6
22802 potentiometer slide cap(painted) potentiometer slide cap(painted) 1
C7
25021 light-transmittable parts of LCD FY0144(ROHS) 3
C8
33478 MK33 pitch/modulation wheel MK33 pitch/modulation wheel 1
C9
A31975 MK33 Function PCB A MK33 Function PCB A kit 1
C10
A31976 MK33 Function PCB B MK33 Function PCB B kit 1
C11
32918 MK33 Assem blies master volume board MK33 Assem blies master volume board kit 1
C8
33478 MK33 pitch/modulation wheel MK33 pitch/modulation wheel 1
C8-1
22039B pitch wheel(painted) pitch wheel(painted) 1
C8-2
22041B modulation wheel(painted) YF8.322.072 1
C8-3
18450 clump weight for pitch/modulation wheel YF8.048.225 1
C8-4
A16273 angle part for pitch/modulation wheel YF8.044.306(3) 2
C8-5
17846 key spring φ0.8*27.5-0.5 1
C8-6
19952
external-tooth washer
φ9 2
C8-7
20516
hex nut
9*0.75 2
C8-8
B32356 control board for pitch/modulation wheel control board for pitch/modulation wheel 1
