M-Audio M-TRACK plus User Manual

23
Technical Specifications
Interface: 24-bit audio / MIDI interface
Features: Stereo, 24-bit inputs/outputs
Sample-rate adjustable up to 48 kHz
Separate gain knob and mic/line / guitar switch for each input
All balanced inputs and outputs
Stereo 1/4" headphone jack
MIDI I/O
S/PDIF I/O
Audio I/O: Mic inputs:
SNR: 97 dB
THD+N: 0.005%
Frequency Response: ±0.35 dB
1/4" guitar/line inputs:
SNR: 96 dB
THD+N: 0.034%
Frequency Response: ±1.2 dB
Analog outputs:
SNR: 97 dB
THD+N: 0.005%
Frequency Response: ±0.35 dB
Power: USB bus power
Dimensions: 6.5" x 4.7" x 2.25"
(W x L x H) 165 mm x 119 mm x 57 mm
Weight: 1.5 lbs.
0.68 kg
* Specifications are subject to change without notice.

M-Audio M-TRACK plus Specifications

General

Type	Audio Interface
Audio Resolution	24-bit/48kHz
USB	USB 2.0
Phantom Power	Yes
Direct Monitoring	Yes
MIDI I/O	No
Inputs	2 x XLR/TRS Combo
Outputs	2 x TRS, 1 x Headphone
Software Included	Ableton Live Lite
