M-Audio OXYGEN49 User Manual

11
Assigning MMC Control to Buttons
The transport functions of some hardware recording devices and DAW applications can be remotely operated via
MMC (MIDI Machine Control) commands. MMC is a specialized transport control protocol and requires a somewhat
different configuration method. The following values need to be specified:
The following example will configure a button to send the MMC
command "Play". Select an assignable button as described earlier in
this guide.
1. Press the Edit button.
2. Press the Select button or Control Select (Ctrl Sel) key.
3. Select a button as described earlier in this guide.
4. Press the Control Assign (Ctrl Asgn) key.
5. Type 149 using the number keys. This sets the button to send
MMC (MIDI Machine Control).
6. Press the Channel Assign (Chan Asgn) key.
7. Enter 127 (Poly On) using the number keys. This ensures all
receiving devices will respond to the MMC messages.
8. Press the Data 2 key.
9. Enter a number from the chart on the side to select the MMC
command for the button. This determines which transport
function will be controlled by this button. For example, enter 2
for the Play command.
10. Press the Enter key.
Key Parameter Value
Control Assign MMC control 149
Channel Assign (example) Device ID 127
Data 2 (example) MMC function 2 (Play)
Number MMC Command
01 Stop
02 Play
03 Deferred Play
04 Fast Forward
05 Rewind
06 Record Strobe
07 Record Exit
08 Record Pause
09 Pause
09 Eject
10 Chase
11 Command Error Reset
12 MMC Reset
