HYDRAULIC FITTING INSTALLATION
TORQUE RECOMMENDATION
Table 1: For 37° & 45° (Machined or Flared) and MegaSeal
®
ssarBleetSeziS
Dash
Fractional
(In.)
Ft-Lbs. Newton-Meters Ft-Lbs. Newton-Meters
Min. Max. Min. Max. Min. Max. Min. Max.
-4 1/4 10 11 13 15 5 6 6-3/4 9
-5 5/16 13 15 18 20 7 9 10 13
-6 3/81719232612151
720
-8 1/2 34 38 47 52 20 24 27-2/
333
-10 5/8 50 56 69 76 34 40 46-1/3 55
-12 3/4 70 78 96 106 53 60 72-1/
382
-16 1 94 104 127 141 74 82 100-1/
2 111
-20 1-1/4 124 138 169 188 75 83 101-1/
2113
-24 1-1/2 156 173 212 235 79 87 107 118
-32 2 219 243 296 329 158 175 21
4237
Table 2: For Flat-Face “O” Ring Seal (Steel)
sreteM-notweN.sbL-tFeziS
Dash
Fractional
(In.)
Min. Max. Min. Max.
-4 1/4 10121416
-6 3/8 18 20 2
427
-8 1/2 32 40 4
354
-10 5/8 46 56 6
075
-12 3/4 65 80 9
0110
-14 7/8 65 80 9
0110
-16 1 92 105 125 240
-20 1-1/4 125 140 170 190
-24 1-1/2 150 180 200 245
