20/56 Transport and storage
Bosch Rexroth AG, A22VG Series 40, RE 93221-01-B/07.2013
6 Transport and storage
▶ Always observe the required ambient conditions for transport and storage, see
chapter6.2 “Storing the axial piston unit” on page 22.
Notes on unpacking can be found in chapter7.1 “Unpacking” on page24.
6.1 Transporting the axial piston unit
The transportation options below exist depending on the weight and duration
of the transport:
t Transport by hand (chapter not relevant for this axial piston unit)
t Transporting with lifting device (eye bolt or lifting strap)
Table 6: Dimensions and weights
Size 45
Weight kg 53
1)
Width mm The dimensions vary with the unit type. The values applicable for your axial
piston unit can be found in the installation drawing (request if necessary).
Height mm
Depth mm
1)
With HT control without boost pump.
The weight specifications may vary depending on the unit type.
6.1.1 Transporting by hand
Axial piston units with a weight of up to 15 kg can be transported manually for a
short time if necessary.
CAUTION! Danger from heavy loads!
There is a danger of health damage when carrying axial piston units.
▶ Use suitable lifting, placement and relocation equipment.
▶ Use your personal protection equipment (e.g. safety glasses, safety gloves,
suitable working clothes, safety shoes).
▶ Do not transport the axial piston unit at sensitive attachment parts (e.g. sensors
or valves).
▶ Carefully place the axial piston unit on the seating to prevent it from being
damaged.
6.1.2 Transporting with lifting device
For transporting, the axial piston unit can be connected to a lifting device via a eye
bolt or a lifting strap.
The axial piston unit can be transported suspended from a eye bolt screwed into the
drive shaft as long as only outward (pulling) axial forces are applied.
▶ For all female threads, use a threaded plug from the same system of units and of
the correct size.
▶ To do this, screw a eye bolt completely into the female thread on the drive shaft.
The thread size is stated in the installation drawing.
▶ Make sure that the eye bolt can bear the total weight of the axial piston unit
plus 20 %.
Dimensions and weights
Transport with eye bolt
