85
power source
• The power source must be exclusively used for air conditioner
(over 10 A).
• In case of installing an air conditioner in a moist place, please in-
stall a ground leakage breaker.
• For installation in other places, use a circuit breaker as far as pos-
sible.
Flare die
A
1. Cut pipe
2. Remove burs
3. Insert flare nut
cutting and flaring work of piping
• Pipe cutting is carried out with a pipe cutter and burs must be re-
moved.
Correct Incorrect
Lean Damaged
flare
Cracking
Correct Incorrect
Partial
flare
Flare too
large
