Removal Procedure
5 Domestic Air Conditioner
stnioPerudecorPpetS
3
Release the marked
hooks (4EA) and then
Pull the front grille out
Horizontally and
remove it
When assembling,
install the front
grille horizontally
so as not to stuff
the flap inside.
When assembling,
make sure the four
hooks are caught
properly.
Hook (4EA)
Hole (4EA)
