7 Domestic Air Conditioner
Removal Procedure
Removal of Heat Exchanger
stnioPerudecorPpetS
1
2
3
Loosen the marked
screws(2EA)
Pull mounting plate
and heat exchanger
bracket and then
release them.
Release the fixture
plate from the base
frame hook and
remove it.
