Your product
Before you start
31 32 33
34
1.
Front handle
2.
Front guard/chain
brake
3.
Saw chain
4.
Guide bar
5.
Sprocket nose
6.
Tension screw
a.
Tension pin
7.
Retaining nut
8.
Cover
9.
Primer
10.
Rear guard
11.
Rear handle
12.
Fixing screw
13.
Air filter cove
14.
Air filte
15.
Spark plug connector
16.
Cylinder fin
17.
Oiling port
18.
Spike bumper
19.
Support pin
20.
Chain catcher
21.
Clutch
22.
Drive sprocket
23.
Recoil starter handle
24.
Choke knob
25.
Throttle interlock
26.
Throttle trigger
27.
Ignition switch (on/off)
28.
Fuel tank cap
29.
Air vents
30.
Chain oil tank cap
31.
Storage box
32.
Combination spanner/
Spark plug wrench
33.
Guide bar cover
34.
Sharpening kit with
instruction manual
