1. Power cord with plug
2. Handle
3. On-Off switch
4. Instruction Manual
a. Cleaning needle
5. Water inlet
6. Hose reel crank
7. Water inlet hose connector
8. Accessories storage compartment (Rotary brush)
9. Accessories storage compartment (Spray gun & extension lance)
10. Accessories storage compartment (Vario &
nozzles)
11. Power cord storage
12. Rotary brush
a. Adaptor for spray gun
b. Adaptor for extension lance
13. Extension lance
a. Unlock button
14.
nozzle
15. High pressure hose
16. Spray gun
a. Connection port
b. Latch
c. Trigger
d. Trigger locking button
17. Detergent tank
a. Detergent tank cap
18. Hose reel
19. Vario nozzle
20. Detergent spray nozzle
21. Patio cleaner
a. Detergent tank
b. Tank cap
c. Detergent spray regulator
22. Screw x
