Before you startBefore you start
2.
Attach the handle (2) to the support of the hose reel (18) using two screws (22).
Tighten the screws using a suitable crosshead screwdriver. (Fig. 2).
2
18
Fig.
2
3. Push the crank (6) into the opening of the reel (18), ensure it clicks in place (Fig. 3).
Fig.
3
6
18
4. Screw the water inlet hose connector
(7) to the water inlet (5) (Fig. 4).
Fig.
4
7
5.
Attach a suitable water hose to the water supply and then attach the other end to
the water hose inlet connector (7) of the product (Fig. 5).
Fig.
5
Ø13 mm
7
NOTE: (7) that protects the product against
Pressure hose and spray gun
1. Unroll completely the high pressure hose
(15) from the hose reel (18) by pulling it.
2.
Push the latch (16b) on the spray gun (16) to open the connecting port and insert
the connector of the high pressure hose (15) (Fig. 6).
3.
Release the latch (16b) to lock the hose (15) in place. Check the connection by
pulling on the hose. It should not pull out.
Fig.
6
A
16b
15
18
15
Accessories
A choice of lances and accessories are supplied with this product. Please check the
are compatible with this product.
