FIG. 2 STEREO MODE
Connect and set the amplifier as shown in Fig. 2 if it is to be controlled with two output channels and to
use two loudspeakers. The high-pass filter must also be activated if the amplifier is also used for satellite
loudspeakers. See Chapter 5.3.
(1) To the car radio, left output
(2) To the car radio, right output
(3) Loudspeaker left
(4) Loudspeaker right
FIG. 3 BRIDGE MODE WITH STEREO CAR RADIO
If the amplifier has to generate more power to operate a subwoofer, connect and set it as shown in Fig.
3. The use of the low-pass filter is described in Chapter 5.2.
(1) To the car radio, left output
(2) To the car radio, right output
(3) Subwoofer
FIG. 4 MONO MODE WITH ONE CAR RADIO WITH SUBWOOFER OUTPUT
(1) To the car radio, subwoofer output
(2) Subwoofer
(3) Audio Cable
FIG. 5 OPERATING ELEMENTS AND IN-/OUTPUTS
(1) Low-level input
(2) Outputs for connecting additional amplifiers
(3) Input-level control
(4) Bass-booster control
(5) Cross-over frequency control for low pass / high pass
(6) Linear (FULL) / low pass filter (LPF) / high pass filter (HPF) option switch
(7) Mono-stereo switch
(8) "On"/"off" switch for the remote control
(9) Connection for volume remote control
