FIG. 1 POWER SUPPLY / REMOTE SWITCH-ON CONNECTION
(1) Terminal for +12 V battery voltage
(2) REM terminal for remote switch-on
(3) GND terminal for the ground, to the battery’s minus pole
(4) Battery
(5) Cable fuse
(6) To your car radio’s automatic aerial connection
If your car is not equipped with an automatic aerial connection, connect this cable’s plus pole (+) to
the ignition lock. An on/off switch should be inserted in this case. Make sure that this switch is
switched off if the amplifier is not used.
FIG. 2 STEREO MODE
Connect and set the amplifier as shown in Fig. 2 if it is to be controlled with two output channels and to
use two loudspeakers. The high-pass filter must also be activated if the amplifier is also used for satellite
loudspeakers. See Chapter 5.3.
(1) To the car radio, left output
(2) To the car radio, right output
(3) Loudspeaker left
(4) Loudspeaker right
FIG. 3 BRIDGE MODE WITH STEREO CAR RADIO
If the amplifier has to generate more power to operate a subwoofer, connect and set it as shown in Fig.
3. The use of the low-pass filter is described in Chapter 5.2.
(1) To the car radio, left output
(2) To the car radio, right output
(3) Subwoofer
FIG. 4 MONO MODE WITH ONE CAR RADIO WITH SUBWOOFER OUTPUT
(1) To the car radio, subwoofer output
(2) Subwoofer
FIG. 5 OPERATING ELEMENTS AND IN/OUTPUTS
(1) Outputs for connecting additional amplifiers
(2) Low-level input
(3) Mono/Stereo switch
(4) Input level control
(5) Cross-over frequency control for the high pass
(6) FULL / HP (high-pass) / LP/BP (bandpass) option switch
(7) Cross-over frequency control for the low pass
(8) Bass-booster control
