SHP20T 7 5/13/16
PRESS PARTS LIST
1 RS6361901 Pressure Gauge 1
2 RS6361902 Nylon Ring 1
3 RS6361903 Ram Assembly 1
4 * Screw 1
5 RS6361905 Adapter 1
6 RS6361906 Upper Round Nut 1
7 Ram Plate 1
8 RS6361908 Lower Round Nut 1
9 * Bolt 8
10 Upper Beam 2
11 * Washer 8
12 * Spring Washer 8
13 * Nut 8
14 * Washer 12
15 * Spring Washer 12
16 * Nut 12
17 RS6361917 Arbor Plates (pair) 1
18 Work Bed 2
19 RS6361919 Pin 2
20 Post 2
21 Foot Base 2
22 * Washer 6
23 * Spring Washer 4
24 * Nut 6
25 * Bolt 4
26 Lower Cross Member 1
27 Bolt 4
28 Tube 4
29 * Bolt 3
30 * Washer 3
31 Pump Assembly Plate 1
32 RS6361932 Pump 1
33 * Bolt 8
34 Support Bar 4
35 RS6361938 Clip 4
36 * Bolt 2
37 RS6361933 Handle 1
38 RS6361934 Screw 1
39 RS6361935 Oil Hose 1
RSSHP20TPLK Product Label Kit (not shown) 1
Index No. Part No. Description Qty. Index No. Part No. Description Qty.
Only index numbers identified by Part Number are available separately.
* Available in Hardware Kit, RS63619HK.
SHP20T
20-TON CAPACIT Y
SHOP PRESS
