a) Daca se apasa vutonul EDIT,
valoarea va fi inregistrata
permanent.
b) Daca se apasa butonul ON/OFF,
se iese din setare fara salvarea
valorii.
a) If the EDIT button is pressed the
value will be stored permanently
b) If the ON/OFF button is pressed
the value will not be stored and it
is possible to exit without saving.
10
LED FLOAT SWITCH:
 Led Activ: afiseaza starea intrarii
auxiliare J5:
 0 indica contactul J5 deschis
 1 indica contactul J5 inchis
LED FLOAT SWITCH:
 Led On: displays the status of the
auxiliary input J5:
 0 the contact J5 is open
 1 the contact J5 is closed
11
 Led Activ: indica faptul ca parametrul
selectat a fost modificat de utilizator
 Led Intermitent: valoarea presiunii
masurate este in afara plajei de
presiune (limitele de presiune sunt intre
0 bar si 9.9 bar)
 Led On: the parameter was changed
by the user
 Led Blinking: the measured pressure
is outside from the pressure range (the
range must be between 0 bar and 9.9
bar)
