24
MSDD18-Li-2
In more detail . . .
Product functions
>
Move the forward / reverse rotation control switch (5) to the left (as seen from the
operator’s position) in order to use the product in a clockwise rotational mode (Fig. 9).
> Move the forward / reverse rotation control switch (4) to the right (as seen from the
operator’s position) in order to use the product in anticlockwise rotational mode
(Fig. 10).
> Move the forward / reverse rotation control switch (4) to the center position to lock
the on/off switch and avoid accidental starting (Fig. 11).
Position
Rotational
direction
Application
Fig. 9
4
drilling into material
screw driving
Fig. 10
4
loosen jammed drill bits
remove screw
Fig. 11
4
lock the on/off switch and avoid accidental starting
NOTE: If you are using the product for the rst time after changing the rotational
direction, a locking sound may be heard. This is normal and does not represent
a defect.
