SPECIFICATIONS
The following is a list of useful specifications.
Examolite
Model TC-440B SD-840B
Light Sources
Blended Daylight, 7500K (D75)
Daylight: 7500K (D75), 6500K (D65), and 5000K
(D50)
Cool White Fluorescent (4150K)
llluminant "A" (2856K)
Number of Lamps
4 per source (8 Total)
4 per fluorescent source, 8 incandescent (16
Total)
Lamps
F40T12/EX fluorescent daylight lamps 33WA19/EX*
incandescent lamps.
*Four metal cups for the bottom of the incandescent lamps
are also provided to enhance the visual content and eliminate
hot spots.
X-Rite seven phosphor fluorescent daylight lamps:
F40T12/75, F40T12/65, and F40T12/50
F40T12/CW fluorescent lamps
60WA/IF incandescent lamps
Dimensions
Length: 48 in (121.19 cm)
Width: 23.75 in (60.3 cm)
Height: 8 in (20.3 cm)
Weight
78.0 lbs (35.4 kg) 90.0 lbs (40.8 kg)
Power Consumption
368 watts 552 watts
Electrical
Requirements
100VAC/50HZ
117VAC/60HZ
220VAC/ 50HZ-240VAC/ 50Hz
Prooflite
Model PLD-440 PLD-840 (Single Source) PLD-840 (Dual Source)
Light Sources
7500K (D75)
6500K (D65)
5000K (D50)
7500K (D75)
6500K (D65)
5000K (D50)
7500K (D75)/6500K (D65)
7500K (D75)/5000K (D50)
6500K (D65)/5000K (D50)
Number of Lamps
4 8 4 per source (8 Total)
Lamps
X-Rite seven phosphor
fluorescent daylight lamps:
F40T12/75
F40T12/65
F40T12/50
Dimensions
Length: 48 in (121.19 cm)
Width: 23.75 in (60.3 cm)
Hei
g
ht: 8 in
(
20.3 cm
)
Weight
57.5 lbs (26.1 kg) 68.0 lbs (30.8 kg) 68.0 lbs (30.8 kg)
Power Consumption
184 watts 368 watts 184 watts
Electrical
Requirements
100VAC/50HZ
117VAC/60HZ
220VAC/ 50HZ-240 VAC/ 50Hz
277VAC/ 60Hz
