MACGREGOR Legacy Series - Sport Panels Installation

7
INSTALLING THE SPORT PANELS
Parts List:
4 - Sport Panels
4 - 15” braces (2 each / for top and bottom panels)
4 - 8” braces (2 each / for side panels)
2 - ¼” 20 x 1” bolts
16 – 3/8” x 1 ½” bolts
32 – 3/8” flat washers
16 – 3/8” nuts
1. Place the top Sport panel onto the scoreboard by lining up a corner at one end and slipping the
panel over the cabinet flange. Be careful not to damage the vinyl graphics on the face of the
scoreboard.
