Mackie d8b v3 - Page 29

A-2
QUICK PARTS
1-24 1-48
MASTER
AUX 7
AUX 8
AUX 5
AUX 6
AUX 1
AUX 3
AUX 2
AUX 4
PAN
SOLO
SHIFT
MASTERS
LEVEL TO TAPE
DIGITAL TRIM
AUX 9 - 10
AUX 11
- 12
PA N
PA N
1-24
25-48
49-72
(TRACK) (MONITOR)
BANK SELECT
EFFECTS
MIC/LINE
TAPE IN
M1MIC
ITEM REF PART #
480-001-00
SW2608Switch
500-033-02
SW2609Switch
500-033-02
D2610LED
304-055-02
Button
760-104-00
SW2610Switch
500-033-02
D2611LED
304-055-02
Button
760-104-00
SW2611Switch
500-033-02
D2614LED
304-055-02
D2613LED
304-055-02
Button
760-104-00
SW2613Switch
500-033-02
D2612LED
304-056-02
Button
760-104-00
SW2614Switch
500-033-02
D2615LED
304-055-02
Button
760-104-00
R2637Pot
130-045-00
D2607LED
304-026-00
Knob
760-063-00
Lens
760-064-00
Button
760-104-00
D2609LED
304-054-02
SW2601Switch
500-033-02
Button
760-104-00
D2609LED
304-054-02
SW2612Switch
Button
500-033-02
760-104-00
ITEM REF PART #
SW2602Switch
500-033-02
D2602LED
304-055-02
Button
760-104-00
SW2603Switch
500-033-02
D2603LED
304-055-02
Button
760-104-04
SW2604Switch
500-033-02
D2606LED
304-055-02
Button
760-104-00
SW2605Switch
500-033-02
D2605LED
304-055-02
Button
760-104-00
SW2606Switch
500-033-02
D2604LED
304-056-02
Button
760-104-00
SW2607Switch
500-033-02
D2608LED
304-055-02
Button
760-104-00
SW2615Switch
500-033-02
D2616LED
304-055-02
Button
760-104-00
SW2616Switch
500-033-02
D2617LED
304-055-02
Button
760-105-00
SW2619Switch
500-033-02
D2620LED
304-055-02
Button
760-105-00
SW2617Switch
500-033-02
D2618LED
304-055-02
Button
760-104-00
SW2618Switch
500-033-02
D2619LED
304-055-02
Button
760-105-00
SW2620Switch
500-033-02
D2621LED
304-054-02
Button
760-105-00
SW2621Switch
500-033-02
D2622LED
304-056-02
NOTE: All small buttons are 760-104-00, later models are 760-117-00
All large buttons are 760-105-00, later models are 760-118-00
All switches are 500-033-02
760-105-00
These parts are on the
Line control surface
(121 board)
