A-10
PARTS
090-071-00 DIGITAL 8 BUS CONSOLE REV A1
ITEM PART NO. DESCRIPTION REV QTY
1 040-138-00 CBL 3P 22GA .098CL 17IN A 1
2 040-141-00 RIB 28GA 26C 8IN PLZD A 5
3 040-142-00 RIB 28GA 40C 8IN PLZD A 4
4 040-143-00 RIB 28GA 25C 4.5IN DSUB A 1
5 040-145-00 RIB 28GA 26C 2.5IN PLZD A 1
6 040-146-00 RIB 28GA 34C 3IN PLZD A 1
7 040-147-00 RIB 28GA 20C 11.5IN PLZD A 1
9 040-149-00 RIB 28GA 34C 10.5IN PLZD A 1
10 040-195-00 RIB 28GA 10C 23IN PLZD A 1
11 040-196-00 RIB 28GA 34C 21IN PLZD A 1
12 040-197-00 RIB 28GA 26C 6IN PLZD A 2
13 040-198-00 RIB 28GA 34C 8.25IN PLZD A 1
14 040-199-00 RIB 28GA 34C 11.5IN PLZD A 1
15 040-200-00 RIB 28GA 34C 18IN PLZD A 1
16 040-202-00 RIB 28GA 26C 20.5IN PLZD A 1
17 040-203-00 RIB 28GA 34C 4IN PLZD A 1
18 040-204-00 RIB 28GA 34C 6.5IN PLZD A 1
20 040-211-00 RIB 28GA 26C 13.5IN PLZD A 1
21 040-212-00 RIB 28GA 20C 8.5IN PLZD A 2
22 040-213-00 RIB 28GA 20C 17.5IN PLZD A 1
19 040-249-00 CBL DATA 25P DSUB MF 18FT A 1
23 040-252-00 RIB 28GA 20C 22 28IN DSUB A 1
24 040-253-00 RIB 18GA 7C .156X1 6.75IN A 1
25 040-254-00 RIB 18GA 8P .156X1 19IN A 1
26 040-255-00 RIB 18GA 5C .156X1 21.5IN A 1
27 040-256-00 DIS 16GA 1007 GRN 25.5IN A 1
28 040-277-00 RIB 28GA 40C 1IN PLZD A 1
29 040-278-00 DIS 16GA 1007 GN/YL 5 Q/L A 1
30 055-108-00 PCB ASSY MIC/LINE METERS 5 A1 1
31 055-109-00 PCB ASSY LINE/MSTR METER 4 A1 1
32 055-110-00 PCB ASSY ANA I/O JACKFLD 2 1
33 055-111-00 PCB ASSY PWR DIST - D8 2 B1 1
34 055-112-00 PCB ASSY DCA - D8 2 1
35 055-113-00 PCB ASSY CODEC - D8 3 1
42 055-120-01 PCB ASSY MIC/CNTRL SURF A1 A1 1
38 055-121-01 PCB ASSY LINE/CTL SURF D8 A1 A1 1
39 055-122-01 PCB ASSY OUT/CTL SURF -D8 A1 A1 1
40 055-124-00 PCB ASSY FADER X 8 - D8 2 A1 2
41 055-125-00 PCB ASSY FADER X 9 - D8 1 A1 1
44 055-154-00 PCB IVL EFFECTS D8 A A1 1
45 055-163-00 PCB ASSY EFFECTS BACKPLN 1 1
47 055-191-00 PCB ASSY JOG WHEEL D8 1 A1 1
37 080-091-00 SA TEST 115PCB D8 1 1
46 080-093-00 SA TEST 164PCB D8 1 1
43 080-094-00 SA TEST 136PCB D8 1 1
36 080-095-00 SA TEST 114PCB D8 1 C1 1
48 080-096-00 SA VFD D8 A A1 1
091-136-00 CONSOLE WARNING SHEET D8 B 1
091-155-00 TAB - IYF - ENGLISH 1998 AR
400-302-00 ADAPTER MIDI A 1
49 550-260-00 SCREEN TOP PANEL D8 2 1
50 550-261-00 PNT FRONT MTR BRIDGE D8 2 1
51 550-262-00 PAINT BOTTOM - D8 2 1
52 550-263-00 FAB SIDE PANEL LEFT D8 2 1
53 550-264-00 FAB SIDE PANEL RIGHT D8 2 1
54 550-273-00 FAB SUB CHASSIS - D8 A 1
Note: The numbers in the first column refer to the
circled numbers in the exploded assembly drawings.
