A-12
PARTS
090-096-XX REV C, REMOTE CPU AND POWER SUPPLY
ITEM PART NO. DESCRIPTION REV QTY
090-096-00 REMOTE PWR SPLY 120V D8 C 1
090-096-01 REMOTE PWR SPLY 230V D8 C 1
1 040-139-00 RIB 28GA 34C 23IN PLZD B 1
2 040-140-00 RIB 28GA 40C 19IN PLZD B 1
3 040-248-00 DIS 18GA 1010 BLU 14 QDX2 A 1
4 040-276-00 RIB 28GA 20C 7.5 M DSUB A 1
6 040-282-00 RIB 28GA 26C DSUB 7.75IN A 1
9 040-286-00 DIS 18GA 1010 BLK 14 QDX2 A 1
10 040-287-00 DIS 18GA 1010 WHT 14 QDX2 1 1
11 040-288-00 DIS 18GA 1010 BRN 14 QDX2 A 1
5 040-294-00 CBL DC PWR BRDSHLD D8PWR A 1
15 055-201-00 PCB ASSY PWR DIST D8 PWR A 1 see chapter 201
16 080-036-00 SA LINEAR SUPPLY - D8 3 A1 1 see subassembly on next page
17 080-065-00 SA ASSY XFMR D8PWR 120V 1 1 120V units
080-065-01 SA ASSY XFMR D8PWR 230V A 1 230V units
19 080-090-03 SA FORMATTED HD VER1.03 B A1 1
50 080-099-00 SA CUT KEYBOARD GASKET A 1
49 080-100-00 SA CUT MOUSE GASKET A 1
18 329-049-03 MICRO PROC PENTIUM 166MHZ A A1 1
20 480-005-00 OEM PCB VIDEO 64 BIT A A1 1
21 480-007-00 COMP PWR SPLY 250W SWITCH A 1
22 480-008-00 FAN MICROPROCESSOR W/HTSK A A1 1
23 480-015-00 DRAM 72P SIMM 8MB 2X32 B 2
24 480-023-00 OEM MOTHER PM9800 INTELTX A 1
25 480-024-00 BRKT BLANK PORT A 4
26 480-025-00 OEM MIDI CARD D8 A A1 1
480-026-00 OEM ETHERNET CARD A A1 1
62 480-029-00 OEM FLOPPY DRV 3.5 BLACK B 1
28 500-040-00 SW DPST PWR RCKR W/LED A 1
7 510-012-00 FUSE SB 2.5A 5X20 250 IEC B 2 120V units
8 510-026-00 FUSE SB 3.15A 5X20MM 250V A 1 120V units
510-012-00 FUSE SB 2.5A 5X20 250 IEC B 1 230V units
510-015-00 FUSE SB 1.6A 5X20 250 IEC B 2 230V units
29 550-356-00 SIDE D8 PWR SPLY A 2
32 550-360-00 FAB CARDRACK D8 PWR SPLY B 1
33 550-361-00 BRKT DISK DRV D8 PWR SPLY A 2
35 550-384-00 FAB CAGE CVR D8 PWR SPLY A 1
36 550-385-00 SCR FNT PANEL D8 PWR SPLY 1 1
38 550-390-00 FAB PLATE CVR VOLT SW D8 A 1
34 550-415-00 FAB SHIELD D8 PWR SPLY A 1
31 550-416-00 PNT TOP D8 PWR SUPPLY A 1
30 550-417-00 FAB CHASSIS D8 PWR SUPPLY A 1
41 700-028-00 SEMS 6-32X1/4 PHP BLKZC B 30
12 700-028-02 SEMS 6-32X3/8 PHP BLKZC B 8
65 700-045-04 SEMS 10-32X3/8 PHP BLKZC A 6
42 700-085-03 SCR PHP M3X6 STL BLK ZC A 4
43 700-086-00 TF 6-32X3/8 FL 100DG BLK A 2
44 701-001-00 SM B 6X3/8 PHP BLKZC B 7
45 705-001-00 KEPNUT 6-32 A 14
46 706-017-00 STDF 4-40X.25 JACKSCREW A 4
47 706-059-00 STDF NYL SNAPIN .5IN NO 6 A 2
48 710-008-00 WASH SPLTLCK NO.4 A 4
712-045-00 GASKET TWIST W/ADH 1.5IN A 2
27 730-001-00 THERMAL JOINT COMPOUND A AR
37 740-001-00 TYRAP 3-1/4L A 5
51 740-003-00 TYRAP 8IN BLK A 1
Note: The numbers in the first column refer to the
circled numbers in the exploded assembly drawings.
