A-14
PARTS
055-108-00 REV A, MIC METER BOARD
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
140-064-00 RESISTOR TF SMT 430 5% R101-124 R201-224 R301-324 R401-424
R501-524 R601-624
212-001-00 CAPACITOR CERAMIC SMT 0.01 10% C101-103 C201-203 C301-303 C401-403
C501-503 C601-603
304-025-00 LED ARRAY, 12 ELEMENT LED101-102 LED201-202 LED301-302
LED401-402
LED501-502 LED601-602
325-012-03 IC, 8 BIT SHIFT REGISTERS 74HC595 U101-103 U201-203 U301-303 U401-403
WITH OUTPUT LATCHES SMD U501-503 U601-603
400-216-00 CONNECTOR PLUG J29
450-108-00 PCB, MIC METERS
055-109-00 REV A, OUTPUT METER BOARD
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
140-025-00 RESISTOR TF SMT 10 5% R2-3 R5-6
140-049-00 RESISTOR TF SMT 100 5% R1 R4 R8
140-062-00 RESISTOR TF SMT 360 5% R801-816
140-064-00 RESISTOR TF SMT 430 5% R101-124 R201-224 R301-324 R401-424
R501-524 R601-624 R701-724
140-123-00 RESISTOR TF SMT 100K 5% R7
212-001-00 CAPACITOR CERAMIC SMT 0.01 10% C1 C101-103 C201-203 C301-303
C401-403 C501-503 C601-603 C701-703
C801-802
304-025-00 LED ARRAY, 12 ELEMENT LED101-102 LED201-202 LED301-302
LED401-402 LED501-502 LED601-602
LED701-702
304-035-00 DISPLAY, 7 SEG RED .36 COM D801-802
7 SEGMENT ANODE DISPLAY
325-007-03 IC, HEX, SCH TRIGGER,INV, SMD 74HC14 U1
325-012-03 IC, 8 BIT SHIFT REGISTERS 74HC595 U101-103 U201-203 U301-303 U401-403
WITH OUTPUT LATCHES SMD U501-503 U601-603 U701-703 U801-802
400-147-00 CONNECTOR STR LCK SHRD 26P .100 X 2 J28
400-217-00 CONNECTOR RECEPTACLE J29
450-109-00 PCB LINE/OUTPUT METERS Z1
601-010-00 FERRITE BEAD, SMT Z=73 FB1-2
