A-16
PARTS
055-110-00 REV A, ANALOG I/O continued
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
302-015-02 ZTVS DIODE, BI-DIRECTIONAL SA12CA D101-102 D201-202 D301-302 D401-402
D501-502 D601-602 D701-702 D801-802
D901-902 D1001-1002 D1101-1102
D1201-1202
320-012-00 I.C. LINEAR SMD NJM4560M U1-6
400-041-00 CONNECTOR XLR PC MTG VERT MALE J22-23
400-100-00 CONNECTOR JACK 1/4 VERT PC J25 J32 J39-40
MOUNT PLSTC
400-147-00 CONNECTOR STR LCK SHRD 26P .100 X 2 J1-2 J7 J9 J43
400-186-00 CONN HDR 40P .100 X 2 STR SHRD J4-6 J10
400-214-00 CONNECTOR JACK 1/4 VERT PC J8 J11-18 J20-21 J26-31 J33-38 J41-42
VERT MOUNT W/1MM LW J44 J102-104 J202-204 J302-304
J402-404 J502-504 J602-604 J702-704
J802-804 J902-904 J1002-1004
J1102-1104 J1202-1204
400-223-00 CONNECTOR XLR PC MTG VERT FML J101 J201 J301 J401 J501 J601 J701 J801
J901 J1001 J1101 J1201
400-269-00 CONN QUICK DISC 250 RIGHT ANGLE J300
450-110-00 PCB, ANALOG I/O JACKFIELD Z1
500-037-00 SWITCH PUSH VERT PC MTG 2P2T SW101 SW201 SW301 SW401 SW501
SW601 SW701 SW801 SW901 SW1001
SW1101 SW1201
601-009-00 FERRITE BEAD, SMT Z=1000 FB1-60 FB101-108 FB201-208 FB301-308
FB401-408 FB501-508 FB601-608
FB701-708 FB801-808 FB901-908
FB1001-1008 FB1101-1108 FB1201-1208
601-010-00 FERRITE BEAD, SMT Z=73 FB61-64
760-003-00 BUTTON, SWITCH RECT, 9X5MM Z2-13
760-028-00 SWITCH EXTENDER, SQ CORE Z14-25
055-111-00 REV B, POWER DISTRIBUTION
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
200-027-02 CAPACITOR MYLAR T&R 0.1 5% C7 C9-12
220-007-00 CAPACITOR LYTIC RADIAL 100UF 10% C6
220-020-00 CAPACITOR LYTIC RADIAL 10,000UF10% C1 C5
220-028-00 CAPACITOR LYTIC RADIAL 4,700UF C3-4
301-001-00 DIODE POWER 1N4002 D3-4 D6
301-010-00 DIODE POWER 1N5404 D1 D5
400-147-00 CONNECTOR STR LCK SHRD 26P .100 X 2 J43
400-173-00 CONN QUICK DISC .250 J101 J201 J301 J401
W/STABLE-LOK TABS
400-219-00 CONNECTOR STR 5P .156 X 1 J42
LOCKING KEYED
400-221-00 CONNECTOR STR 7P .156 X 1 J50
LOCKING KEYED
400-224-00 CONNECTOR STR 8P .156 X 1 J41
LOCKING KEYED
400-296-00 RECEPTACLE, MALE, 24P, METAL J1
#28 SHELL
450-111-00 PCB, DIGITAL 8-BUS: POWER DISTRIBUTION Z1
706-056-00 STANDOFF, SWAGE, 6-32 X .688L Z2-5
711-012-00 PIN, CONNECTOR Z6-24
