Mackie d8b v3 - Page 59

A-31
PARTS
055-121-00 REV A, LINE CONTROL SURFACE
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
130-045-00 POT 12MM ENDLESS ROT 50KG R1301 R1401 R1501 R1601 R1701 R1801
R1901 R2001 R2101 R2201 R2301 R2401
R2637
130-049-02 POT 9MM HORIZ, 25MM SHAFT 50KG R116 R216 R316 R416 R516 R616 R716
R816 R916 R1016 R1116 R1216
140-025-00 RESISTOR TF SMT 10 5% R13-14 R21-22
140-049-00 RESISTOR TF SMT 100 5% R15-16 R24 R26 R30
140-051-00 RESISTOR TF SMT 120 5% R6 R9 R121 R221 R321 R421 R521 R621
R721 R821 R921 R1021 R1121 R1221
140-059-00 RESISTOR TF SMT 270 5% R1303-1304 R1317-1318 R1403-1404
R1417-1418 R1503-1504 R1517-1518
R1603-1604 R1617-1618 R1703-1704
R1717-1718 R1803-1804 R1817-1818
R1903-1904 R1917-1918 R2003-2004
R2017-2018 R2103-2104 R2117-2118
R2203-2204 R2217-2218 R2303-2304
R2317-2318 R2403-2404 R2417-2418
R2638-2645 R2648-2650 R2652
R2654-2659
140-064-00 RESISTOR TF SMT 430 5% R1302 R1305-1316 R1319 R1402
R1405-1416 R1419 R1502 R1505-1516
R1519 R1602 R1605-1616 R1619 R1702
R1705-1716 R1719 R1802 R1805-1816
R1819 R1902 R1905-1916 R1919 R2002
R2005-2016 R2019 R2102 R2105-2116
R2119 R2202 R2205-2216 R2219 R2302
R2305-2316 R2319 R2402 R2405-2416
R2419 R2646-2647 R2651 R2653
R2660-2661 R2669-2677
140-068-00 RESISTOR TF SMT 620 5% R1320-1321 R1420-1421 R1520-1521
R1620-1621 R1720-1721 R1820-1821
R1920-1921 R2020-2021 R2120-2121
R2220-2221 R2320-2321 R2420-2421
140-097-00 RESISTOR TF SMT 10K 5% R23 R25 R1322-1329 R1422-1429
R1522-1529 R1622-1629 R1722-1729
R1822-1829 R1922-1929 R2022-2029
R2122-2129 R2222-2229 R2322-2329
R2422-2429 R2678-2701
140-114-00 RESISTOR TF SMT 47K 5% R31
140-117-00 RESISTOR TF SMT 62K 5% R7
140-123-00 RESISTOR TF SMT 100K 5% R17-20
145-000-00 RESISTOR SMT 0 5% R12 R28
145-293-00 RESISTOR MF SMT 1K10 1% R8
145-318-00 RESISTOR MF SMT 2K00 1% R2 R10
145-346-00 RESISTOR MF SMT 3K57 1% R118 R218 R318 R418 R518 R618 R718
R818 R918 R1018 R1118 R1218
145-361-00 RESISTOR MF SMT 5K11 1% R4-5
145-389-00 RESISTOR MF SMT 10K0 1% R1 R3 R104-105 R113-114 R204-205
R213-214 R304-305 R313-314 R404-405
R413-414 R504-505 R513-514 R604-605
R613-614 R704-705 R713-714 R804-805
R813-814 R904-905 R913-914 R1004-1005
R1013-1014 R1104-1105 R1113-1114
R1204-1205 R1213-1214
