A-33
PARTS
055-121-00 REV A continued
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
320-012-00 IC LINEAR SMD NJM4560M U1 U9 U101 U201 U301 U401 U501 U601
U701 U801 U901 U1001 U1101 U1201
321-003-00 IC LINEAR POS 3 TERM LM 7805 U3
VOLTAGE REGULATOR
325-003-03 IC, ANALOG MUX, 8 CH SMD 4051B U5-7 U10
325-006-03 IC, DCDR/DEMUX SMD 74HC138 U4
325-012-03 IC, 8 BIT SHIFT REGISTERS 74HC595 U1301-1303 U1401-1403 U1501-1503
WITH OUTPUT LATCHES, SMD U1601-1603 U1701-1703 U1801-1803
U1901-1903 U2001-2003 U2101-2103
U2201-2203 U2301-2303 U2401-2403
U2613-2617
325-025-03 IC, 8 BIT SHIFT REGISTER 74HC597 U1304 U1404 U1504 U1604 U1704 U1804
WITH INPUT LATCHES, SMD U1904 U2004 U2104 U2204 U2304 U2404
U2618-2620
325-048-03 IC, SMD, 12-STAGE BINARY 74HC4040 U8
RIPPLE COUNTER
325-053-03 IC, SMD, SCH TRIGGER HEX INV. 74AC14 U2
400-147-00 CONNECTOR STR LCK SHRD 26P .100 X 2 J36
400-183-00 CONN HDR 26P .100 X 2 RTA SHRD J3
400-184-00 CONN HDR 40P .100 X 2 RTA SHRD J6
400-207-00 CONNECTOR HDR RTA SHROUD 3P .098x1 J60
450-121-00 PCB, LINE CONTROL SURFACE Z37
480-001-00 MICROPHONE ELEMENT M1
500-033-02 SWITCH, TACT 6MM SQR 260GF SPST SW1301-1306 SW1401-1406
SW1501-1506 SW1601-1606
SW1701-1706 SW1801-1806
SW1901-1906 SW2001-2006
SW2101-2106 SW2201-2206
SW2301-2306 SW2401-2406
SW2601-2621
601-009-00 FERRITE BEAD, SMT Z=1000 FB1-26
601-010-00 FERRITE BEAD, SMT Z=73 FB27-33
706-032-00 LED SPACER, NYLON .300 Z13-36
706-033-01 STANDOFF, SWAGE, 4-40 X .542L Z1-12
760-063-00 KNOB, V-POT Z38-49
760-064-00 LENS, V-POT DISPLAY” Z50-61
760-104-00 SM TACTILE BUTTON B2601-2615 B2617
760-104-01 SM TACTILE BUTTON REC/RDY B1301 B1401 B1501 B1601 B1701 B1801
B1901 B2001 B2101 B2201 B2301 B2401
760-104-04 SM TACTILE BUTTON ASSIGN B1302 B1402 B1502 B1602 B1702 B1802
B1902 B2002 B2102 B2202 B2302 B2402
760-104-05 SM TACTILE BUTTON WRITE B1303 B1403 B1503 B1603 B1703 B1803
B1903 B2003 B2103 B2203 B2303 B2403
760-105-00 LG TACTILE BUTTON B2619-2623
760-105-02 LG TACTILE BUTTON SOLO B1305 B1405 B1505 B1605 B1705 B1805
B1905 B2005 B2105 B2205 B2305 B2405
760-105-03 LG TACTILE BUTTON MUTE B1306 B1406 B1506 B1606 B1706 B1806
B1906 B2006 B2106 B2206 B2306 B2406
760-105-04 LG TACTILE BUTTON SELECT B1304 B1404 B1504 B1604 B1704 B1804
B1904 B2004 B2104 B2204 B2304 B2404
