A-43
PARTS
090-126-xx REV 12, REMOTE CPU & POWER SUPPLY-CE
PART NO. DESCRIPTION REV QTY
090-126-00 D8 PWR SPLY 120V CE 12 A2 1 Pre- Nov 99 models
090-126-01 D8 PWR SPLY 230V CE 12 A2 1
090-126-02 D8 PWR SPLY 100V CE 12 A2 1
040-139-00 RIB 28GA 34C 23IN PLZD B 1
040-140-00 RIB 28GA 40C 19IN PLZD B 1
040-276-00 RIB 28GA 20C 7.5 M DSUB A 1
040-282-00 RIB 28GA 26C DSUB 7.75IN A 1
040-294-00 CBL DC PWR BRDSHLD D8PWR A 1
055-201-00-01 PCB ASSY PWR DIST D8 PWR A2 A1 1 see chapter 201
080-036-00 SA LINEAR SUPPLY - D8 A1 A1 1 see subassemby on page A-47
080-099-00 SA CUT KEYBOARD GASKET A 1
080-100-00 SA CUT MOUSE GASKET A 1
080-107-00 SA XFMR 120V CE D8 A A1 1 120V units-see page A-47
080-107-01 SA XFMR 230V CE D8 A A1 1 230V units
080-107-02 SA XFMR 100V CE D8 A 1 100V units
080-108-00 SA PWR SW W/CBLS D8 A A1 1 see subassemby on page A-47
080-109-00 SA HARD DR/FLOPPY DR D8 B1 B2 1 see subassemby on page A-47
080-113-00 SA MOTHER BOARD MOD D8 1 A1 1
080-124-00 SA DC PWR SPLY D8 A 1
091-161-00 COMPUTER WARNING SHT D8 B 1
091-200-00 REAL TIME OS 2.0 LABEL A A1 1
329-049-03 MICRO PROC PENTIUM 166MHZ A A1 1
480-005-00 OEM PCB VIDEO 64 BIT A A1 1
480-008-00 FAN MICROPROCESSOR W/HTSK A A1 1
480-015-00 DRAM 72P SIMM 8MB 2X32 A 2
480-024-00 BRKT BLANK PORT A 4
480-025-00 OEM MIDI CARD D8 A A1 1
480-026-00 OEM ETHERNET CARD A A1 1
510-001-00 FUSE SB 1A 5X20MM 250V UL B 1 120V units
510-026-00 FUSE SB 3.15A 5X20MM 250V A 1 120V units
510-029-00 FUSE SB 2.5A 5X20 250V UL A 1 120V units
510-002-00 FUSE SB .5A 5X20 250V IEC C 1 230V units
510-012-00 FUSE SB 2.5A 5X20 250 IEC B 1 230V units
510-015-00 FUSE SB 1.6A 5X20 250 IEC B 1 230V units
510-011-00 FUSE SB 4A 5X20 250V IEC B 1 100V units
510-025-00 FUSE SB 1.25A 5X20MM 250V B 1 100V units
510-026-00 FUSE SB 3.15A 5X20MM 250V A 1 100V units
550-356-00 SIDE D8 PWR SPLY A 2
550-384-00 FAB CAGE CVR D8 PWR SPLY A 1
550-385-00 SCR FNT PANEL D8 PWR SPLY A 1
550-390-00 FAB PLATE CVR VOLT SW D8 A 1
550-415-00 FAB SHIELD D8 PWR SPLY A 1
550-451-00 FAB CHASSIS D8 PWR SUPPLY B 1
550-452-00 PNT TOP D8 PWR SUPPLY A 1
550-453-00 FAB CARDRACK D8 PWR SPLY B 1
700-028-00 SEMS 6-32X1/4 PHP BLKZC B 39
700-028-02 SEMS 6-32X3/8 PHP BLKZC B 8
700-045-04 SEMS 10-32X3/8 PHP BLKZC A 6
700-086-00 TF 6-32X3/8 FL 100DG BLK A 2
701-001-00 SM B 6X3/8 PHP BLKZC B 7
705-001-00 KEPNUT 6-32 A 14
706-017-00 STDF 4-40X.25 JACKSCREW A 4
706-059-00 STDF NYL SNAPIN .5IN NO 6 A 2
710-008-00 WASH SPLTLCK NO.4 A 4
730-001-00 THERMAL JOINT COMPOUND A AR
