Mackie d8b v3 - Page 78

A-50
PARTS
PART NO. DESCRIPTION REV QTY
090-126-00 D8 PWR SPLY 120V CE 21 A4 1
040-139-00 RIB 28GA 34C 23IN PLZD B 1
040-140-00 RIB 28GA 40C 19IN PLZD B 1
040-276-00 RIB 28GA 20C 7.5 M DSUB A 1
040-339-00 CBL DC PWR BRDSHLD D8PWR B 1 NOTE: New Part Number
055-201-00-01 PCB ASSY PWR DIST D8 PWR A2 A1 1
080-036-00 SA LINEAR SUPPLY - D8 B A1 1
080-107-00 SA XFMR 120V CE D8 A A1 1
080-108-00 SA PWR SW W/CBLS D8 B A1 1
080-109-00 SA HARD DR/FLOPPY DR D8 B3 B3 1
091-161-00 COMPUTER WARNING SHT D8 B 1
091-200-00 REAL TIME OS 2.0 LABEL A A1 1
329-087-03 MICRO PROC CELERON 300MHZ A 1
480-005-00 OEM PCB VIDEO 64 BIT A A1 1
480-024-00 BRKT BLANK PORT A 3
480-026-00 OEM ETHERNET CARD A A1 1
480-030-00 PC PWR SPLY 250W 90-240V B A1 1
480-039-00 OEM PCB MOTHER CB50-BX A A1 1
480-043-00 OEM FAN MICROPROC A A1 1
480-053-00 OEM MIDI CARD WINMAN1X1 A A1 1
480-064-00 SDRAM 32MB 4MX64 DIMM 3V A 1 NOTE: This is one 32MB SDRAM
510-001-00 FUSE SB 1A 5X20MM 250V UL B 1
510-026-00 FUSE SB 3.15A 5X20MM 250V A 1
510-029-00 FUSE SB 2.5A 5X20 250V UL A 1
550-356-00 SIDE D8 PWR SPLY A 2
550-384-00 FAB CAGE CVR D8 PWR SPLY A 1
550-385-00 SCR FNT PANEL D8 PWR SPLY A 1
550-390-00 FAB PLATE CVR VOLT SW D8 A 1
550-415-00 FAB SHIELD D8 PWR SPLY A 1
550-535-00 FAB CARDRACK D8 PWR SPLY A 1
550-542-00 PNT TOP D8 CPSU A 1
550-543-00 FAB CHASSIS D8 CPSU B 1
700-028-00 SEMS 6-32X1/4 PHP BLKZC B 39
700-028-02 SEMS 6-32X3/8 PHP BLKZC B 8
700-045-04 SEMS 10-32X3/8 PHP BLKZC A 6
700-086-00 TF 6-32X3/8 FL 100DG BLK A 2
701-001-00 SM B 6X3/8 PHP BLKZC B 7
705-001-00 KEPNUT 6-32 A 14
706-017-00 STDF 4-40X.25 JACKSCREW A 4
706-059-00 STDF SNAPIN .5IN NO 6 SVC A 2
710-008-00 WASH SPLTLCK NO.4 A 4
730-001-00 THERMAL JOINT COMPOUND A AR
740-001-00 TYRAP 3-1/4L A 10
740-003-00 TYRAP 8IN BLK A 4
740-007-01 GROMMET STRIP MEDIUM A AR
740-023-00 FLT CBL CLMP NYL LOCK 40C A 1
760-128-00 DUST COVER 25P DSUB FEM A 1
760-129-00 DUST COVER 25P DSUB MALE A 1
760-130-00 DUST CVR 9S/15HD DSUB F B A 2
790-001-00 BAG POLY 20 X 30 4MIL A 1
790-011-00 BAG POLY 20 X 7 X 30 4MIL A 1
800-085-00 BOX D8 PWR SUPPLY A 1
810-074-00 FOAM ENDS D8 PWR SUPPLY A 2
810-081-00 INSERT PWR CBL TRAY D8PS A 1
820-212-00 ERRATA SH D8 CPU PORT CHG 1
840-171-00 LBL FUSE 1.0 AMP A 1
090-126-00 REV 21, Remote CPU and Power supply
Latest Parts List July 2001
