Mackie d8b v3 - Page 82

B-4
CHIPS
CHIPS
055-123-00 REV E, LINEAR POWER SUPPLY
321-008-00 I.C. ADJ POS 3 TERM LM317T U2
VOLTAGE REGULATOR
321-009-00 I.C. ADJ NEG 3 TERM LM337T U1
VOLTAGE REGULATOR
055-125-00 REV A, 9-WAY FADER
320-004-00 I.C. LINEAR SMD NJM4560 U1-2 U10 U101-102 U201-202 U301-302
U401-402 U501-502 U601-602 U701-702
U801-802 U904
321-003-00 I.C. LINEAR POS 3 TERM LM 7805 U3
VOLTAGE REGULATOR
325-003-03 IC, ANALOG MUX, 8 CHL SMD 4051B U7-8
325-006-03 IC, DCDR/DEMUX SMD 74HC138 U6
325-012-03 IC, 8 BIT SHIFT REGISTERS 74HC595 U903 U915
WITH OUTPUT LATCHES, SMD
325-048-03 IC, SMD, 12-STAGE BINARY 74HC4040 U9
RIPPLE COUNTER
325-053-03 IC, SMD, SCH TRIGGER HEX INV 74AC14 U4
329-016-03 IC, 12 CHANNEL DAC, SMD AD8804 U914
055-124-00 REV A, 8-WAY FADER
320-004-00 I.C. LINEAR SMD NJM4560 U1-2 U10 U101-102 U201-202 U301-302
U401-402 U501-502 U601-602 U701-702
U904
321-003-00 I.C. LINEAR POS 3 TERM LM 7805 U3
VOLTAGE REGULATOR
325-003-03 IC, ANALOG MUX, 8 CH SMD 4051B U12
325-012-03 IC, 8 BIT SHIFT REGISTERS 74HC595 U903
WITH OUTPUT LATCHES, SMD
325-048-03 IC, SMD, 12-STAGE BINARY 74HC4040 U15
RIPPLE COUNTER
325-053-03 IC, SMD, SCH TRIGGER HEX INV. 74AC14 U4
329-015-03 IC, 8 CHANNEL DAC, SMD AD8803 U908
