Page #26 background imageLoading...
Page #26 background image
DL806 and DL1608 Owners Manual
26
Specications Continued...
Analog Inputs
Connectors: .................................................................................. 1-12: XLR Balanced, 13-16: Combo XLR / TRS Balanced [DL1608]
1-4: XLR Balanced, 5-8: Combo XLR / TRS Balanced [DL806]
XLR Mic Pre: .....................................................................................................................................................................................................Onyx
Input Impedance: ............................................................................... 1-12: 3k , 13-16: 3 k mic [XLR], 30 k line [1/4"] [DL1608]
1-4: 3k , 5-8: 3 k mic [XLR], 30 k line [1/4"] [DL806]
Max Input Level: .............................................................................................................................................................................XLR: +21 dBu
1/4": +30 dBu
Gain: ............................................................................................................................................................................................. XLR: 0 to 60 dB
1/4": –20 to 40 dB
48V Phantom Power (XLR): .............................................48 VDC, 10 mA max per mic, with up to eight simultaneously [both]
5 mA max per mic, with up to 16 simultaneously [DL1608]
Analog Main Out L/R
Connectors: .....................................................................................................................................................................................XLR Balanced
Output Impedance: .....................................................................................................................................................................................600
Max Output Level: .................................................................................................................................................................................. +21 dBu
Analog Aux Sends
Connectors: .................................................................................................................................................... 1/4" TRS Impedance Balanced
(Supports balanced / unbalanced operation)
Output Impedance: ........................................................................................................................ 240 Balanced, 120 Unbalanced
Max Output Level: .................................................................................................................................................................................. +21 dBu
Analog Headphone Out
Connector: ....................................................................................................................................................................................1/4" TRS Stereo
Max Output Level: .........................................................................................................................................................+18.0 dBu into 600
+19.5 dBu max into 100 k
