Appendix B: Technical Info
SDR24/96 Specifications
Electronic
Frequency Response (Digital, 48 kHz sampling rate): 20 Hz to 20 kHz (+ 0 dB, – 0.5 dB)
Harmonic Distortion: 0.005% @ 1 kHz sine wave at –1 dBFS with 20 kHz
brick-wall low-pass filter
Dynamic Range: 108 dB digital (A-Weighted)
Adjacent Channel Crosstalk (+10 dBu at 1 kHz): –90 dB
Digital
Quantization: 16-bit and 24-bit, selectable
Sample Rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Computer
Internal CPU: Hitachi H8S 2357 w/128k internal Flash memory
Internal RAM: 8 MB DRAM
Hard Disk
Internal Capacity: 20 GB (> 90 minutes, 24 tracks at 48 kHz)
Mackie M90 Media Capacity: 20 GB (> 90 minutes, 24 tracks at 48 kHz)
Hard Disk Seek Time: 9.5 ms
Hard Disk Throughput: 295 megabits/sec
I/O
Analog: Balanced, +4 dBu nominal, +22 dBu maximum,
DB25F
Digital: ADAT optical, 24-bit, 128X oversampling
MIDI: MIDI IN/MIDI OUT, 5-pin DIN
SMPTE: 1/4" TRS
Word Clock: BNC
ADAT Sync: DB9F
Serial 9-Pin: DB9F
Physical
Height: 5.25" (133 mm)(3 RU)
Width: 19.00" (483 mm)
Depth: 13.25" (337 mm)
Weight: 14 lbs. (6.4 kg)
Electrical
Operating Voltage: 100-240 VAC, 50/60Hz
Power Consumption: 30W
Optional
Remotes: Remote 24, Micro Remote
