FLAT Voicing Mode – No question about this
speaker mode; it’s flat! This plug-and-play mode
is perfect for singer-songwriters and listening to
mastered music.
LIVE Voicing Mode – This mode features a low
frequency roll-o to get rid of unwanted thumps
and adds boost and sparkle to mid-range and high
frequencies.
SPEECH Voicing Mode – This mode features
a significant low frequency roll-o to get rid of
unwanted thumps. It also adds boost and sparkle to
mid-range and high frequencies, critical for speech
applications. Lastly, a compressor has been added
to help control spoken audio levels. This plug-and-
play mode is perfect for larger venue applications
where speech is the primary audio source in need of
clear and precise intelligibility.
CLUB Voicing Mode – This mode is full range, but
focuses on increased bass and brilliant high frequencies.
This is the place to start for most DJ / music playback
applications.
MONITOR Voicing Mode –Monitor mode was designed
primarily to remove unwanted low frequency buildup
while also improving mid-range articulation for the
artist(s). This mode should only be engaged when
the speaker is in its monitor orientation and coupled with
a stage or other hardwood floor... if not, the speaker won’t
sound right.
SRM | V-Class Loudspeakers Frequency Response Legend
FLAT LIVE SPEECH CLUB MONITOR
100 200 500 2k 5k 10k 20k50
Frequency (Hz)
1k
SRM20 | V-Class Frequency Graph
