3
OPERATION INSTRUCTIONS
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE USE AND KEEP THEM FOR FUTURE REFERENCE.
YOUR CHILDREN’S SAFETY MAY BE AFFECTED IF YOU DO NOT FOLLOW THESE INSTRUCTIONS.
3 SEAT HARNESS SYSTEM OPERATION
WARNING: AVOID
SERIOUS INJURY FROM
FALLING OR SLIDING
OUT. ALWAYS USE SEAT
HARNESS SYSTEM.
ADJUST THE HARNESS TO FIT YOUR CHILD’S SIZE
TO FIT HARNESS, place child in seat:
A Pull shoulder straps over the child’s shoulder then attach
to the waist clips by sliding strap loops onto the hooks.
B Insert both waist clips into the clasp, shoulder straps are
secured once the clips are fastened.
C Adjust strap lengths by sliding buckles. Belt and harness
should be snug.
TO RELEASE HARNESS:
D Press the center button on both the front and back of
the clasp simultaneously to release.
2 TO OPERATE BRAKES
The brakes are located on the wheels at the back
of the buggy.
A TO ENGAGE BRAKES: With foot, push down
either brake pedal located on of each rear wheel
until you hear a click.
B TO RELEASE BRAKES: With foot, kick either
brake pedal up.
NOTICE: Brakes shall be used when: stationary,
making adjustments, especially on a hill or during
the loading and unloading of children.
1 TO OPEN THE BUGGY
A Release storage clip.
B Grasp handles and fully open the buggy.
C Using the foot, push the footplate all the way
down until you hear a click.
The Primary lock is now engaged.
NOTICE: Make sure both locks are set and look
horizontal to the ground.
4 TO OPERATE FRONT WHEEL SWIVEL LOCKS
A USE FOOT TO LOCK SWIVELS:
With foot, fully press the back of the pedal
located between each wheel until you hear
a click.
B USE FOOT TO UNLOCK SWIVELS:
With foot, press the front of the pedal located
between each wheel until you hear a click.
en
B A
A
B C
CLICK
A B
C
C
C
C
C
D
D
D
A
B B
