4
7 TO ADJUST SEAT RECLINE
A TO RECLINE SEAT BACK: Lift both hand grips located
behind the seat to release seat locks and slide the seat back
to desired position. Lower hand grips to engage locks on
both sides.
B TO RAISE SEAT BACK: From rear of buggy
push seat back to original upright or desired intermediate
position.
ASSEMBLY INSTRUCTIONS
6 TO OPERATE THE ADJUSTABLE LEG REST
A Raise leg rest.
B Push in the lever on the leg rest to lock.
C To release, simply pull the lever back on base of
adjustable leg and allow the leg rest to return.
8 TO ATTACH THE HOOD
A With buggy open clip the hood to the handle
tubes just above the retaining blocks.
B Wrap adjustable straps around handle tubes.
C Place rear apron behind seat back.
D Extend hood and press down on side hinges to
lock open.
TO TILT HOOD:
E Fully unzip back panel.
F Tilt hood forward.
G The hood is removed by firmly pressing down
the clip release tabs.
9 TO ADJUST HANDLE LENGTHS
A Press triggers.
B Slide handles until triggers locate in one of
3 positions. Release triggers to lock.
5 TO FOLD THE BUGGY
Fold the hood back, place the seat to an upright position,
remove contents of the shopping bag, then fasten the harness.
A Using foot, lift up on footplate to release primary lock until
it pops up.
B Using foot, press down on the lever sticking out on the right
hand side of the frame.
C Whilst pressing the lever down with your foot, push the
handles forward and inwards.
D Compress folded buggy and engage storage clip.
Use the handle to carefully carry your buggy.
NOTICE: The buggy should always open and fold easily.
Do not force it. It may be necessary to re-read the instructions.
A
B
C
A
C D
B
B
A
B
A
A
B
D
A
E
C
F
G
