Macma MM2315 - Parts List; Component Identification

NO.
DESCRIPTION
Q’TY
NO.
DESCRIPTION
Q’TY
1
Clamp
3
45
Thread column
2
2
Locating arm
1
46
Locking nut
1
3
Locating arm fixing plate
1
47
Screw M6X16
1
4
Extension support
1
48
Nylon washer
1
5
Extension platform
1
49
Clamp M20X1.5
3
6
Sliding block
4
50
KJD18(--) Switch
1
7
Belt cover
1
50A
KJD12 Switch box
1
8
Handle
8
51
Washer 9X28X3
1
9
Sanding belt 2515*152 60P
1
52
Motor roller
1
10
Handle
1
53
Motor washer
1
11
Belt replacing plate
1
54
Key 6X12
1
12
Handle
1
55
Base
1
13
Bracket
1
59
Big locking handle
1
14
Sanding belt platform
1
62
Nut
1
15
Tension bar
1
63
Stopping iron
1
16
Table
1
64
Pointer
1
Sticking graphite plate960X180X2
1
65
Sliding iron
1
17
Spring
1
66
Scale
1
18
Roller arm
1
67
Handle
1
19
Driver roller
1
67A
Big washer 6
4
20
Shaft
1
68
Bolt M6X25
3
21
Globular sleeve
1
68A
Bolt M6X12
1
22
Nut
1
69
Spring washer 6
14
23
Screw
1
70
Bolt M8X30
1
24
Driver wrench
1
71
Motor
1
25
Nut M12
1
72
Nut M6
1
26
Handle
2
73
Washer 6
22
27
Scale fixing plate
1
74
Shaft coupling
1
Scale
1
75
Elastomer
1
28
Washer
1
76
Screw M8X55
2
29
Spring
1
77
Ring 19
1
30
Upper guide bush
1
77A
Ring 42
2
31
Sliding shaft
1
78
Bearing 6004
2
32
Lower guide bush
1
79
Washer 8
1
33
Bearing bolt
1
80
Shaft coupling
1
34
Bearing 60/7
1
81
Washer 8
32
35
Nut M6
3
81A
Big washer 8
13
36
Bearing base
1
82
Bolt M8X35
8
37
Motor base
1
83
Bolt M8X45
1
38
Screw M8X35
5
84
Nut M8
22
39
Screw M6X20
8
84A
Locking nut M8
1
40
Pin
1
85
Nut M5
1
41
Fixing plate
1
85A
Locking washer 5
1
42
Fixing block
2
86
43
Nylon block
1
87
Washer 5
1
44
Up-and-down board
2
88
Screw M5X16
1
89
Pin 6X32
1
124
Cone-shaped gear I
1
90
Screw M8X25
4
125
Ring 80
1
