Macnaught Retracta AB100 - Spare Part List

RP32ML Issue 13 © 2014 Page 17 of 20
Spare Part List
Item
Description
AB100
AR100
AR200
AW150
AW100
1 Inlet side plate order RP34s order RP34s order RP34s order RP34s order RP34s
2 Swivel Shaft RS27s (NPT) RS48s (NPT) RS27s (NPT) RS27s (NPT)
3 Swivel body RS100s (BSP) RS26s (BSP) RS46s (BSP) RS26s (BSP) RS26s (BSP)
4 Circlip
5 Drum assembly RP35-Black RP35-Black RP35-Black RP35-Black RP35-Black
6 Outer case assembly RP36Cs* RP36Cs* RP36Cs* RP36Cs* RP36Cs*
7 Outer case - plain
8 Tension plate assembly RP114A-Blacks RP114A-Blacks RP114A-Blacks RP114A-Blacks RP114A-Blacks
9 Latching plate assembly Order - RP34s Order - RP34s Order - RP34s Order - RP34s Order - RP34s
10 Latching plate (for comp set) (for comp set) (for comp set) (for comp set) (for comp set)
11 Carry handle order RP36Cs* order RP36Cs* order RP36Cs* order RP36Cs* order RP36Cs*
12 Seal set BS115VS BS115VS BS115VS BS115VS BS115VS
13 Hose assembly kit RH99s (BSP) RH35s (BSP) RH22s (BSP) RH61s (BSP) RH86s (BSP)
(Inc hose stopper) RH101s (NPT) RH36s (NPT) RH17S (NPT) RH15s (NPT) RH74s (NPT)
14 Hose stopper Z10s Z10s Z40s Z10s Z10s
15 Inlet sw ivel assembly N/A N/A N/A N/A N/A
16 inlet adapter N/A N/A N/A N/A N/A
17 Bearing set (incl screw s) N/A N/A N/A N/A N/A
18 Nozzle set N/A N/A N/A N/A N/A
Locking baracket order BU100 order BU100 order BU100 order BU100 order BU100
Std w all bracket BU100 incl RB9s BU100 incl RB9s BU100 incl RB9s BU100 incl RB9s BU100 incl RB9s
Feeder hose assy N/A N/A N/A N/A N/A
Item
Description
AW200
CW100
DR100
FG100
GR100
1 Inlet side plate order RP34s order RP34s order RP34s order RP34s order RP34s
2 Swivel Shaft RS48s (NPT) RS48s (NPT) RS27s (NPT) RS44s (NPT)
3 Swivel body RS46s (BSP) RS46s (BSP) RS1s RS26s (BSP) RS43s (BSP)
4 Circlip
5 Drum assembly RP35-Black RP35-Black RP35-Black RP35-Black RP35-Black
6 Outer case assembly RP36Cs* RP36Cs* RP36Cs* RP36Cs* RP36Cs*
7 Outer case - plain
8 Tension plate assembly RP114A-Blacks RP114A-Blacks RP114A-Blacks RP114A-Blacks RP114A-Blacks
9 Latching plate assembly Order - RP34s Order - RP34s Order - RP34s Order - RP34s Order - RP34s
10 Latching plate (for comp set) (for comp set) (for comp set) (for comp set) (for comp set)
11 Carry handle order RP36Cs* order RP36Cs* order RP36Cs* order RP36Cs* order RP36Cs*
12 Seal set BS115VS BS115VS BS115VS BS115VS
13 Hose assembly kit RH83s (BSP) RH40s (BSP) RH3s RH140s (BSP) RH45s (BSP)
(Inc hose stopper) RH87s (NPT) RH44S (NPT) RH49S (NPT)
14 Hose stopper Z40s Z40s Z10s Z10s Z10s
15 Inlet sw ivel assembly N/A N/A N/A N/A SB6s
16 inlet adapter N/A N/A N/A N/A RS40s
17 Bearing set (incl screw s) N/A N/A N/A N/A RS36s
18 Nozzle set N/A RH51s N/A N/A N/A
Locking baracket order BU100 order BU100 order BU100 order BU100 order BU100
Std w all bracket BU100 incl RB9s BU100 incl RB9s BU100 incl RB9s BU100 incl RB9s BU100 incl RB9s
Item
Description
HW100
HWP100
OLP100
OMP100
WP100
1 Inlet side plate order RP34s order RP34s order RP34s order RP34s order RP34s
2 Swivel Shaft RS52s (NPT) RS90s (NPT) RS51s (NPT) RS51s (NPT) RS68s (NPT)
3 Swivel body RS64s (BSP) RS85s (BSP) RS50s (BSP) RS50s (BSP) RS67s (BSP)
4 Circlip
5 Drum assembly RP35-Black RP35-Black RP35-Black RP35-Black RP43-Black
6 Outer case assembly RP36Cs* RP36Cs* RP36Cs* RP36Cs* RP36Cs*
7 Outer case - plain
8 Tension plate assembly RP114A-Blacks RP114A-Blacks RP114A-Blacks RP114A-Blacks RP114A-Blacks
9 Latching plate assembly Order - RP34s Order - RP34s Order - RP34s Order - RP34s Order - RP34s
10 Latching plate (for comp set) (for comp set) (for comp set) (for comp set) (for comp set)
11 Carry handle order RP36Cs* order RP36Cs* order RP36Cs* order RP36Cs* order RP36Cs*
12 Seal set BS115Es RS85s (BSP) BS115Vs BS115Vs BS115Vs
RS90s (NPT)
13 Hose assembly kit RH41s (BSP) RH64s (BSP) RH81s (BSP) RH84s (BSP) RH50s (BSP)
(Inc hose stopper) RH46s (NPT) RH82s (NPT) RH85S (NPT) RH63s (NPT)
14 Hose stopper Z40s Z10s Z40s Z40s Z10s
15 Inlet sw ivel assembly N/A N/A N/A N/A N/A
16 inlet adapter N/A N/A N/A N/A N/A
17 Bearing set (incl screw s) N/A N/A N/A N/A N/A
18 Nozzle set N/A N/A N/A N/A N/A
Locking baracket order BU100 order BU100 order BU100 order BU100 order BU100
Std w all bracket BU100 incl RB9s BU100 incl RB9s BU100 incl RB9s BU100 incl RB9s BU100 incl RB9s
