Macro-Tech 24x6 - Typical Phase Response

Page 28
Reference Manual
Macro-Tech
®
24x6 & 36x12 Power Amplifiers
TECHRON TEF
®
+45˚
0˚
–45˚
100 1 K 10 K 20 K
FREQUENCY
(
Hz
)
Fig. 6.4 Typical Phase Response
Fig. 7.1 Macro-Tech 24x6 Power Draw, Current Draw and
Thermal Dissipation at Various Duty Cycles
