Cables and Connectors
Cable Assemblies:
WWW.MADBOY-AUDIO.COM
14
1/8" TRS plug connector
L
shield/ground
R
1/4" TS plug connector
XLR female connector
+
shield
-
1
3
2
Connectors:
Unbalanced 1/4" TS
plug connector
tip =
signal
sleeve =
ground
tip
sleeve
1/8" TRS
plug connector
tip
sleeve
ring
tip = left channel
sleeve = ground
ring = right channel
XLR female
12
3
+
shield
1
2
3
-
1/8" TRS plug connector
L
R
1/8" TRS plug connector
RCA connector
RCA connector
tip = signal
sleeve = ground
tip
sleeve
shield/ground
