16
Figure 16
DISPLAY (FOR MCSFLW27W/MCSFLW27S ONLY)
e
a
d e f g
b
c
a. Cycle Indicator: Indicates stage of wash/dry cycle.
•
: Prewash • : Wash • : Rinse • : Spin
•
: Time Save
b. Clock: Indicates time left until the end of wash/dry cycle.
c. Feature Indicator: Indicates features that are active.
•
Sound: Indicates that sounds are on. When unlit, unit is muted.
•
Door Lock: Machine is locked for duration of cycle.
•
Child Lock: Child lock is on.
•
Add a Garment
d. Water Temperature: Indicates the selected temperature.
e. Spin Speed: Indicates the selected spin speed.
f. Soil Level Indicator: Indicates the selected soil level.
g. Additional Functions: Indicates additional functions selected.
•
Extra Rinse •
Easy Iron •
Prewash
Press 3 sec. to set My Cycle
h. Soil: Press [Soil] to increase time for heavier soiled items.
• There are three (3) soil levels options.
• Each bar increases the base wash time by 15 minutes.
i. Function: Use to select functions during the wash cycle
j. Child Lock: Press [Delay] and [Temp] at the same time for 3 seconds to Unlock/Lock the control panel.
• On/Off Button will still function.
k. My Cycle: After a wash cycle is modified, hold down [Spin] to save your settings.
• You can quickly choose this cycle for your next wash by turning the dial to My Cycle.
• Override saved settings by holding the [Spin] button down again after a different cycle and options are
selected.
l. Sound: Press the [Soil] button for 3sec. to turn the sound on or off.
