Magic-Pak HWC8 V Series - Page 9

Page 9 of 16507388-01 Issue 1732
Airows and Heating Temperature Rises as a Function of External Static Pressure
Model
Rise
Range
(°F)
Mid
Rise
(°F)
Indoor
Blower
Speed
Unit
Voltage
(V)
0.1“ w.c. 0.2“ w.c. 0.3“ w.c. 0.4“ w.c.
SCFM
Temp
Rise
(°F)
SCFM
Temp
Rise
(°F)
SCFM
Temp
Rise
(°F)
SCFM
Temp
Rise
(°F)
HWC8(R/N)240912A 25 - 55 40
LOW
208 365 49 340 53 315 N/A 285 N/A
230 425 42 405 44 380 47 350 51
MED *
208 445 40 415 43 390 46 365 49
230 515 35 485 37 455 39 430 42
HIGH
208 620 29 585 31 555 32 520 34
230 685 26 650 28 610 29 570 31
HWC8(R/N)360912A 35 - 65 50
LOW
208 365 N/A 340 N/A 315 N/A 285 N/A
230 425 63 405 N/A 380 N/A 350 N/A
MED
208 445 60 415 65 390 N/A 365 N/A
230 515 52 485 55 455 59 430 62
HIGH *
208 620 43 585 46 555 48 520 52
230 685 39 650 41 610 44 570 47
HWC8(R/N)360918A
HWC8(R/N)360924A
25 - 55 40
LOW
208 480 N/A 465 N/A 450 N/A 435 N/A
230 610 44 590 45 565 47 535 50
MED *
208 750 36 715 38 685 39 655 41
230 810 33 770 35 735 37 700 38
HIGH
208 860 31 815 33 770 35 735 37
230 880 30 835 32 790 34 750 36
HWC8(R/N)480918A
HWC8(R/N)480924A
35 - 65 50
LOW
208 480 N/A 465 N/A 450 N/A 435 N/A
230 610 59 590 61 565 63 535 N/A
MED *
208 750 48 715 50 685 52 655 55
230 810 44 770 46 735 49 700 51
HIGH
208 860 42 815 44 770 46 735 49
230 880 41 835 43 790 45 750 48
HWC8(R/N)600918A
HWC8(R/N)600924A
45 - 75 60
LOW
208 480 N/A 465 N/A 450 N/A 435 N/A
230 610 73 590 N/A 565 N/A 535 N/A
MED
208 750 60 715 63 685 65 655 68
230 810 55 770 58 735 61 700 64
HIGH *
208 860 52 815 55 770 58 735 61
230 880 51 835 54 790 57 750 60
HWC8(R/N)480930A 30 - 60 45
TAP 1
(HEAT)
208 or 230 735 49 700 51 670 53 640 56
TAP 2
(HEAT) *
208 or 230 825 43 795 45 770 46 745 48
TAP 3
(HEAT)
208 or 230 895 40 865 41 840 43 810 44
TAP 4
(COOL)
208 or 230 800 765 735 715
TAP 5
(COOL)
208 or 230 880 845 820 795
HWC8(R/N)600930A 45 - 75 60
TAP 1
(HEAT)
208 or 230
735 61 700 64 670 67 640 70
TAP 2
(HEAT) *
208 or 230 825 54 795 56 770 58 745 60
TAP 3
(HEAT)
208 or 230 895 50 865 52 840 53 810 55
TAP 4
(COOL)
208 or 230 800 765 735 715
TAP 5
(COOL)
208 or 230 880 845 820 795
N/A: Do not operate unit in heating mode using this blower speed at this external static pressure. Outside of temperature rise range.
* As shipped speed for heating operation
Table 2.
