Magic-Pak MCE4 Series - Page 6

Page 6 of 14 507860-01Issue 1927
Airow Performance as a Function of External Static Pressure
Model
Indoor Blower
Speed
0.1 “w.c. 0.2 “w.c. 0.3 “w.c. 0.4 “w.c. 0.5 “w.c.
SCFM Watts HP SCFM Watts HP SCFM Watts HP SCFM Watts HP SCFM Watts HP
*MCE4-11-091*P
(FAN) 355 28 0.04 320 31 0.04 275 35 0.05 230 38 0.05 160 42 0.06
(COOL)† 375 31 0.04 330 33 0.04 285 37 0.05 N/A N/A N/A N/A N/A N/A
(COOL) N/A N/A N/A N/A N/A N/A 390 55 0.07 370 58 0.08 330 62 0.08
0 kW
TAP 4 (HEAT)* 375 31 0.04 330 33 0.04 285 37 0.05 240 40 0.05 180 44 0.06
TAP 5 (HEAT) 465 47 0.06 425 51 0.07 390 55 0.07 370 58 0.08 330 62 0.08
3 kW
TAP 4 (HEAT)* 430 41 0.05 410 45 0.06 385 49 0.07 N/A N/A N/A N/A N/A N/A
TAP 5 (HEAT) 520 58 0.08 500 63 0.08 475 68 0.09 440 73 0.10 400 77 0.10
5 kW
TAP 4 (HEAT)* 525 59 0.08 505 65 0.09 480 69 0.09 N/A N/A N/A N/A N/A N/A
TAP 5 (HEAT) 615 81 0.11 590 88 0.12 560 94 0.13 530 99 0.13 500 103 0.14
*MCE4-11-121*P
TAP 1 (FAN) 355 28 0.04 320 31 0.04 275 35 0.05 230 38 0.05 160 42 0.06
TAP 2 (COOL)
†
420 40 0.05 380 42 0.06 355 46 0.06 N/A N/A N/A N/A N/A N/A
TAP 3 (COOL) N/A N/A N/A 480 62 0.08 445 66 0.09 415 70 0.09 380 74 0.10
0 kW
TAP 4 (HEAT)* 420 40 0.05 380 42 0.06 355 46 0.06 315 50 0.07 275 54 0.07
TAP 5 (HEAT) 515 58 0.08 480 62 0.08 445 66 0.09 415 70 0.09 380 74 0.10
3 kW
TAP 4 (HEAT)* 430 41 0.05 410 45 0.06 385 49 0.07 N/A N/A N/A N/A N/A N/A
TAP 5 (HEAT) 520 58 0.08 500 63 0.08 475 68 0.09 440 73 0.10 400 77 0.10
5 kW
TAP 4 (HEAT)* 525 59 0.08 505 65 0.09 480 69 0.09 N/A N/A N/A N/A N/A N/A
TAP 5 (HEAT) 615 81 0.11 590 88 0.12 560 94 0.13 530 99 0.13 500 103 0.14
*MCE4-11-181*P
TAP 1 (FAN) 355 28 0.04 320 31 0.04 275 35 0.05 230 38 0.05 160 42 0.06
TAP 2 (COOL)
†
660 103 0.14 640 109 0.15 610 114 0.15 580 119 0.16 550 124 0.17
TAP 3 (COOL) 725 131 0.18 710 135 0.18 685 140 0.19 660 146 0.20 640 152 0.20
0 kW
TAP 4 (HEAT)* 660 103 0.14 640 109 0.15 610 114 0.15 580 119 0.16 550 124 0.17
TAP 5 (HEAT) 725 131 0.18 710 135 0.18 685 140 0.19 660 146
0.20 640 152 0.20
3 kW
TAP 4 (HEAT)* 430 41 0.05 410 45 0.06 385 49 0.07 N/A N/A N/A N/A N/A N/A
TAP 5 (HEAT) 520 59 0.08 500 63 0.08 475 67 0.09 440 72 0.10 400 77 0.10
5 kW
TAP 4 (HEAT)* 525 60 0.08 505 65 0.09 480 70 0.09 N/A N/A N/A N/A N/A N/A
TAP 5 (HEAT) 615 81 0.11 590 88 0.12 560 95 0.13 530 100 0.13 500 103 0.14
7 kW
TAP 4 (HEAT)* 685 108 0.14 670 116 0.16 645 122 0.16 N/A N/A N/A N/A N/A N/A
TAP 5 (HEAT) 790 153 0.21 770 160 0.21 750 166 0.22 720 172 0.23 700 177 0.24
10 kW
TAP 4 (HEAT)* 790 153 0.21 770 160 0.21 750 166 0.22 N/A N/A N/A N/A N/A N/A
TAP 5 (HEAT) 890 211 0.28 870 217 0.29 850 222 0.30 820 226 0.30 800 230 0.31
N/A: Do not operate unit using this blower speed at this external static pressure.
† As shipped speed for Cooling operation. Blower speed must be eld adjusted to Speed Tap 3 for higher duct static applications.
* As shipped speed for Heating operation. Blower speed must be eld adjusted to Speed Tap 5 for higher duct static applications.
Table 3. Blower Performance (208V or 230V)
