KULLANMA KILAVUZU
MIG/MAG KAYNAK MAKİNESİ
RS 350 M
RS 400 M - RS 400 MW
RS 500 M - RS 500 MW
www.oerlikon.com.tr
MIG/MAG WELDING MACHINE
USER MANUAL

Table of Contents

Questions and Answers

  • M
    Mrs. Anna DoyleAug 15, 2025
    What to do if I am having trouble in welding operation with my MAGNAWELD Welding System?
    • T
      Thomas SimmonsAug 15, 2025
      If you are experiencing trouble in welding operations with your MAGNAWELD Welding System, several factors could be the cause. First, the contact tip size might be incorrect or worn out, in which case you should replace it. Another potential issue is insufficient pressure on the rolls; adjust the pressure as explained in Section 3.5. Also, check if the CO heater fuse (F3) has blown and replace it if necessary. Finally, ensure that the shielding gas flow is appropriate. Check the gas and its adjustment, and if you cannot adjust the gas, contact an authorized service.
  • L
    Lisa DuarteAug 18, 2025
    Why is wire feeder working but wire is not fed in my MAGNAWELD Welding System?
    • W
      wfrederickAug 19, 2025
      If the wire feeder in your MAGNAWELD Welding System is working but the wire isn't feeding, it could be due to a couple of reasons. First, the drive roll might not be appropriate for the wire diameter, so select the appropriate drive roll. Second, the pressure on the rolls might not be sufficient; in this case, adjust the pressure as explained in Section 3.5.
  • G
    gblankenshipAug 22, 2025
    What to do if wire feeder doesn’t work and torch doesn’t perform the triggering on my MAGNAWELD Welding System?
    • N
      Nicholas BellAug 22, 2025
      If the wire feeder isn’t working and the torch isn’t triggering on your MAGNAWELD Welding System, the fuse “F1” may be blown out. Try changing the fuse to resolve this issue. If that doesn't work, the electronic card may be out of order, and you should contact your authorized technical service.
  • K
    Kayla HowardAug 26, 2025
    Why ventilator does not function in my MAGNAWELD Welding System?
    • K
      Katherine CastanedaAug 26, 2025
      If the ventilator in your MAGNAWELD Welding System does not function, it may be due to a blown fuse “F2”. Replace the fuse. If the issue persists, the ventilator motor may be out of order, and you should contact your authorized technical service.
  • W
    Wendy LeeAug 28, 2025
    What to do if voltmeter or ampermeter is not working in my MAGNAWELD RS 350 M Welding System?
    • E
      Evan StephensAug 28, 2025
      If the voltmeter or ampermeter is not working on your MAGNAWELD Welding System, the fuse “F4” may be blown. Replace the fuse. If the issue persists, the electronic card may be out of order, and you should change the fuse.
  • M
    michaeljohnsonSep 1, 2025
    Why heater socket is not working in my MAGNAWELD Welding System?
    • C
      Catherine ValentineSep 1, 2025
      If the heater socket on your MAGNAWELD Welding System is not working, the fuse “F3” may be blown. Replace the fuse.
  • S
    simontinaSep 4, 2025
    What to do if my MAGNAWELD RS 350 M machine does not work?
    • J
      John KingSep 4, 2025
      If your MAGNAWELD Welding System machine does not work, this could be due to a contactor being out of order, in which case you should contact your authorized technical service. Alternatively, the electronic card may be out of order.
  • T
    Theresa MedinaSep 7, 2025
    Why is my MAGNAWELD RS 350 M machine working noisily?
    • S
      staceygonzalesSep 7, 2025
      If your MAGNAWELD Welding System machine works noisily, the contactor may be out of order. Contact your authorized technical service.
  • H
    Heidi SanchezSep 12, 2025
    What to do if welding current isn’t stabilized and/or cannot be adjusted on my MAGNAWELD RS 350 M Welding System?
    • C
      Cindy DoyleSep 12, 2025
      If the welding current isn’t stabilized or cannot be adjusted on your MAGNAWELD Welding System, some diodes in the power pack may be out of order. Contact your authorized technical service.
