What to do if Magnum Dimensions Inverter AC output has sensed an overload?
If the AC output has sensed an overload or short circuit and shut down, check the load connected to the output. Reduce the load, and then restart the Magnum Dimensions Inverter.
What to do if my Magnum Dimensions CSW2012-X Inverter internal temperature is too high?
If the internal temperature of your Magnum Dimensions Inverter is too high and the unit has shut down, turn the unit off and wait 15 minutes before restarting. Make sure that the unit’s airflow and fans are not blocked and ensure the unit’s fans are running.
What to do if my Magnum Dimensions Inverter has no AC output and the Status LED is red?
If there is no AC output and the Status LED is red, the Magnum Dimensions Inverter has shut down. Verify the error condition, and then make the necessary correction.
What to do if the GFCI outlet trips when connecting a load to my Magnum Dimensions CSW2012-X Inverter?
If the GFCI outlet trips as soon as the load is connected to either L2/ N2 AC Output terminals or into the GFCI outlet, there is a neutral-to- ground bonding in the load side. Locate and remove the neutral-to-ground bonding on the AC load side. If the output of the inverter is connected to an existing distribution panel/ box, make sure the neutral- to-ground connections inside the panel/box use separate bus bars—the neutral one is isolated from the chassis ground. Otherwise, consider using the AC 1 (L1/N1) Output.
What to do if my Magnum Dimensions CSW2012-X Inverter has no power coming into the unit?
If there is no power coming into the Magnum Dimensions Inverter, check the battery DC fuse, the disconnect switch (if installed), and the AC input source. The AC input branch breaker is either tripped or turned off.
What should I do if my Magnum Dimensions CSW2012-X Inverter input battery voltage is too high?
If the input battery voltage is too high and the unit has shut down, check the battery voltage, or determine if any external charger is connected to the battery bank.
Why does my Magnum Dimensions CSW2012-X Inverter AC output turn on and off?
The AC output of the Magnum Dimensions Inverter turns on and off when Search mode (PS2) is enabled and the AC load is less than 10W. This is a normal condition when in Search mode. The load connected must be below the AC load sense threshold of 10W, so the power output will be pulsed every 10 seconds for checking the load.
What does it mean when my Magnum Dimensions CSW2012-X input battery voltage is low and has initiated a warning alarm?
If the input battery voltage is low and has initiated a warning alarm (@11.2 VDC), recharge the battery. The Magnum Dimensions Inverter will shut down shortly.
What to do if my Magnum Dimensions Inverter is in inverter mode with a large AC output load?
If the Magnum Dimensions Inverter is in inverter mode and the connected AC output load is large and close to the shutdown limit, reduce the load.
What can I do if my Magnum Dimensions CSW2012-X internal temperature is high?
If the internal temperature of the Magnum Dimensions Inverter is high and close to the thermal shutdown limit, reduce the load and check if the unit’s ventilation is blocked.
Disclaims liability and outlines use limitations for the inverter.
Explains hazard symbols and lists critical safety precautions for operation.
Introduces the inverter, its front panel features, and back panel features.
Explains how the inverter works and the advantages of pure sine wave output.
Covers planning, guidelines, unpacking, and tools required before installation.
Provides guidance on choosing a suitable location and mounting the inverter.
General requirements for DC and AC wiring, including sizing and protection.
Specifics on DC wire sizing, overcurrent protection, and grounding.
Step-by-step guide for connecting the inverter to the battery bank.
Information on AC wire sizing, overcurrent protection, and terminal connections.
Guides through the process of connecting AC conductors.
Outlines the functional test procedure after installation.
Explains Inverter Mode and By-Pass Mode.
Details the inverter's display panel, status indicators, and buttons.
Discusses how different types of loads affect inverter performance.
Lists error codes and their corrective actions.
Provides solutions for common inverter issues.
Lists the technical specifications of the inverter.
Guidance on battery bank size, types, and wiring configurations.
Maintenance steps for inverter/battery longevity, storage, and GFCI testing.
Details certifications, safety standards, and FCC information.
Details warranty terms, conditions, and how to receive service.
General| Continuous Output Power | 2000W |
|---|---|
| Input Voltage | 12 VDC |
| Output Voltage | 120 VAC |
| Output Frequency | 60 Hz |
| Waveform | Modified Sine Wave |
| Protections | Overload, Over Temperature, Short Circuit |
