CAT D11 - HYDRAULICS
www.magomhrc.com
2005-XXX
DETAILS 1/16 Hydraulic kit for D11 Bruder Model
CONTENTS Hydraulic cylinders, Hydraulic pump, Hose, Hydraulic valve,
Hydraulic oil and Y connectors (8)
Please note that this product is not a toy and not suitable for youngters under the age of 16. Technical details may be
subject to changes and modifications. All images and designs are property of MAGOM HRC. For any doubts or
questions, please contact us throught www.magomhrc.com.
CONNECTING DIAGRAM
Connect the hose as shown in the picture. Use our recommended oil.
If you have any doubts about the assembling process, please contact us to: info@magomhrc.com
Rear
Front
Blade up/down
Blade angle
Ripper up/down
Ripper angle
It is recommended
using a spring to
prevent hose
expansion.
CAUTION !
This product IS NOT A TOY. NOT SUITABLE FOR PEOPLE UNDER 16.
This is a hobby product and some experience is required.
If you have any doubts or questions, please contact with our team: info@magomhrc.com
