8-26
© Copyright Mahindra & Mahindra Ltd. 082014
8.33.4 Trip Meter, Set and Mode Button
A Set Button B Mode Button
The top row of the LCD display gives the trip meter A & B details. It displays the
elapsed distance travelled since the last trip reset. There are two trip meters (A/B)
which can be reset by SET (A) button.
Odometer and trip meter are displayed only when the ignition is ON. To cycle
between trip A & B press and release MODE (B) button for a second.
8.33.5 Engine Coolant Temperature Gauge
The engine coolant temperature bar graph functions only when the ignition is
switched ON. It indicates the instantaneous engine coolant temperature. The coolant
temperature varies with changes in weather, load on engine and driving pattern. LCD
bar rises from Cold (C) towards Hot (H).
FEATURES AND CONTROL
