© Copyright Mahindra & Mahindra Ltd. 082014
4-7
Symbol Warning Lamp/Tell Tale Lamp Pre-check Lamp Status Action/Remarks
Seat Belt Warning Lamp
No
Continuously ON
Indicates driver seat belt not fastened. If tell tale is not turning OFF even after
fastening the driver seat belt, contact an Authorized Mahindra Dealer for
assistance
Low Fuel Warning Lamp
No
Continuously ON The fuel level in the fuel tank is low. Re-fuel immediately to an avoid empty tank
TPMS Warning Lamp
No
Continuously ON or Blinking
Indicates low tyre pressure or possible malfunction in TPMS. Refer to the TPMS
section in the FEATURES AND CONTROL/WHEELS AND TIRES chapter for further
details
Start/Stop Lamp
No
Continuously ON or Blinking
Continuously ON: Engine is in auto stop mode
Blinking: Stop/Start is about to stop the engine
Fast Blinking: Stop/Start is inhibited due to unhealthy battery conditions
4WD High
No
Continuously ON Indicates transmission is in 4WD High
4WD Low No
Continuously ON
Indicates transmission is in 4WD Low
Malfunction Lamp (OBD)
Continuously ON till Engine
Starts
Continuously ON
There is a potential malfunction related to emission control system, contact an
Authorized Mahindra Dealer immediately
Battery Charging Warning Lamp
Continuously ON till Engine
Starts
Continuously ON
Indicates malfunction in the charging system. Contact an Authorized Mahindra
Dealer for assistance
INSTRUMENT CLUSTER OVERVIEW
