2-7
2.5.1 Engine Compartment Fuse Box
W12B31
W12B06
The engine compartment fuse box is located adjacent to vehicle battery. Follow the
below steps to remove the fuse cover;
• Slightly press/nudge the fuse cover towards the vehicle LHS and remove the left
snap lock
• Further, push top cover towards vehicle RHS and remove/pull the cover
completely
W12B07
SPARE
FUSE
CAB BATT- 2
6
0A
ABS
MOTOR
40A
EMS MAI N
REL
AY I / P
30 A
STAR
TER
SOLENOID
60 A
EC MI NI
FUSE
B+
60 A
FUEL
PUMP
RELAY
GNS
RELAY
SPARE
HORN 1 5A
A/C RELAY/GNS
10 A
CBSB/WIF/ ES S
5A
SPARE
EGR/FMU/BPA
15A
FRONT FOG LAMP
15A
EMS BATT-2
10A
LOW BEAM
15A
EMS BATT-1
10A
HIGH BEAM 1 5A
SPARE
HFM 10A
AC COMP
CLUTCH 15A
BRAKE SWI TCH
15A
ABS/CONDENSOR
FAN 30A
CONDENSOR
FAN
RELAY
STARTER
RELAY
COOLING
FAN HIGH
RELAY
COOLING
FAN LOW
RELAY
HORN
RELAY
HIGH
RELAY
LOW
RELAY
FOG
RELAY
AC
COMP
RELAY
SPARE
RELAY
SPARE
RELAY
GNS
RELAY
CAB BATT- 1
60 A
CAB
BATT- 3
60 A
SPARE
FUSE
SPARE
FUSE
SPARE
FUSE
SPARE
FUSE
SPARE
FUSE
SPARE
FUSE
ECU/
SPARE
RELAY
ECU/
S
PARE
RELAY
BEAM
LAMP
BEAM
1 2 3 4 5 6 7
45 46
4443
37 38
39 40
33
41 42
3231
15 16 17 18 19 20 21 22
30 29 28 27 26 25 24 23
34
35 36
8 9 10 11 12 13 14
W12B34
Fuse No
Fuse Rating
Circuit
1 60A
Battery — 3
2 40A ABS
3 60A Starter Solenoid
4 30A
EMS Relay
5
Spare Fuse
6
Spare Fuse
7
Spare Fuse
8 60A
Battery — 1
