2-18
© Copyright Mahindra & Mahindra Ltd.012016
Rotate the lock stud by hand in anti-clockwise direction and take
the complete tool kit organiser out.
Slowly lift the spare wheel up and take out.
2.7.3 Wheel bolt Loosening
Wrap the tip of a screw driver with cloth, insert it near the lugs of
the wheel cap (if equipped) and pry the cap away from the wheel.
Do not try to pry off the wheel cap by hand alone. Take due care
in handling the wheel cap to avoid unexpected personal injury.
S12B15
Always loosen the wheel bolts before raising the vehicle. Turn the
wheel bolts counter clockwise to loosen as per the crisscross
sequence shown. To get maximum leverage, fit the spanner to the
bolt so that the handle is on the left side. Grab the spanner near the
end of the handle and push down on the handle. Be careful that the
spanner does not slip off the bolt. Do not remove the bolts, but
loosen them by one or two turns.
Do not apply force with your legs (or stand) on the wheel
spanner while loosening/tightening the wheel bolts.
2.8 Jack Points
Front jack up point - On the side sill in between the groove just behind
the front wheels.
S12B16
