© Copyright Mahindra & Mahindra Ltd. 012016
8-3
8.2.1 Tip-Tap ORVM Adjustment (if equipped)
Tip Tap ORVM’s can be adjusted by hand in the direction as
indicated by the arrows. Adjust the mirror as required to bring the
rear traffic vision as desired.
8.2.2 Manual (Joystick) ORVM Adjustment (if equipped)
Manual ORVM’s can be adjusted by the joystick provided on the
ORVM trim. Adjust the joy stick as required to bring the rear traffic
vision as desired.
8.2.3 Electric ORVM Adjustment (if equipped)
The electric exterior mirror adjustment switch is located on the
RHS of instrument panel adjacent to the head lamp levelling switch.
The joystick on the switch can be used to select the left/right
mirror and also to adjust the respective mirror.
FEATURES AND CONTROL
