HYDRAULIC VALVE AND HARDWARE
Reference Description Part No. Qty.
1..............................Hydraulic Hose Assembly 3/8" x 22"
................................¾” JICF x ¾” JICF 90° "In" and “Out” ......................................0582-2508808022 ....................2
2..............................Hydraulic Hose Assembly 3/8” x 32"
................................¾” JICF x ¾” JICF 90° "PB”.....................................................0582-1508808032....................1
3..............................Hydraulic Adapter 90˚
................................9/16" ORBM x 9/16" JICM........................................................0586-3106-406.........................2
4..............................Hydraulic Adapter Straight
...............................3/4" ORBM x ¾” JICM..............................................................0586-1108-408 .........................3
5..............................Hydraulic Adapter Straight
................................9/16” ORBM x 9/16” JICF ........................................................0586-1106-506 .........................4
6..............................Hydraulic Adapter 45°
................................9/16” ORBM x 9/16” JICM........................................................0586-2106-406.........................2
7..............................Hydraulic Adapter 90°
................................3/4" JICF x ¾” JICM.................................................................0586-3408-508.........................3
8..............................Quick Coupler Female .............................................................0580-6203 ................................4
9..............................Orifice Plate .116” ID................................................................0580-6307 ................................1
10............................Hydraulic Control Valve............................................................0580-6311 ................................1
11 ............................Spacer Plate.............................................................................1204-3160 ................................1
12............................Single handle controller Mount ................................................1204-3147 ................................1
13............................Dual Flange..............................................................................1408-3010 ................................1
14............................Cable Adapter Kit ....................................................................1408-3032................................1
15............................Valve Mount .............................................................................1204-3146................................1
16............................Hex Head Cap Screw 5/16"-18 x .625"....................................0545-2023 ................................3
17............................Lockwasher 5/16".....................................................................0544-2009 ................................3
18............................Flatwasher 5/16" ......................................................................0543-2006 ................................5
19............................Cover Plate ..............................................................................1204-3151 ................................1
20............................Spacer......................................................................................1204-3150 ................................1
21............................Stover hex Locknut 5/16”-18....................................................0546-1121 ................................5
22............................Hex Head Cap Screw 5/16"-18 x 3.5"......................................0545-2036 ................................3
23............................Hex Head Cap Screw 3/8”-16 x 1.25”......................................0545-2052 ................
................4
24............................Stover hex Locknut 3/8”-16......................................................0546-1119.................................4
25............................Hex Head Cap Screw 5/16"-18 x 1.25”....................................0545-2027 ................................2
26............................Tie Strap Blue .14" x 5.5" .........................................................0554-2001................................2
................................Tie Strap Red .14" x 5.5"..........................................................0554-2002 ................................2
................................Tie Strap Yellow .14" x 5.5" ......................................................0554-2003 ................................2
................................Tie Strap Green .14" x 5.5" ......................................................0554-2004 ................................2
27............................Single handle controller (Complete)........................................1408-3025 ................................1
28............................Tie Strap Black 5/16" x 14".......................................................0554-1013 ................................5
29............................Jam Nut M16-1.5......................................................................0559-2016 ................................2
30............................Jam Nut M6-1...........................................................................0559-2002 ................................2
31............................Control Cable 1000mm............................................................1408-3041 ................................2
32............................Knob.........................................................................................1409-3170 ................................1
35 Series 4WD, Model - 3535 & 4035 Loader June’08
